|Product Name:||Acoustic Partition Walls||Application:||Banquet Room Partitions|
|Aluminium Alloy:||6063-T6||Frame Thickness:||65 Mm|
|Function:||Room Divider / Partition||Style:||Modern|
Banquet Room Acoustic Partition Walls Sound Proof Collapsible Operable Partition
Acoustic Partitions Melamine Finish
The banquet room acoustic partition walls series is the most popular specification range of fully operational single or double roller soundproof partitions systems. The noise reduction can be up to 50dB, achieved with a combination of operable top and bottom seals, high performance multiple sound absorbing material in banquet room acoustic partition walls and panel assembly design which allows noise reduction between the frame and the outer layer.
The vertical channel of each banquet room acoustic partition wall panel contains a polymer insert that is acoustic sealed when the panels are placed as a wall. The sound insulation partition walls are available in three thicknesses, 65mm, 80mm and 100mm, depending on the acoustic rating (from 30dB to 50dB).
When the operable seal is retracted, the banquet room acoustic partition walls panel slide easily along a unique aluminum overhead rail system (no floor rails are required). The telescopic end panel allows the walls to be locked off to complete the acoustic seal. The rail and carrier systems make sure banquet room acoustical partition wall is easy to operate and change direction, allowing panel stacking in countless configurations.
For aesthetic appeal, it is possible to provide almost any decorative finish, including veneer, laminates, walls, carpets, whiteboards and decorative lacquers.
Advantages of Acoustic Partitions System
The banquet room acoustic partition walls are supported from the ceiling track, so there is no floor track to get in the way, no tripping hazard, and no gap to collect debris. When an acoustic bottom seal is required, the seal is activated from within the operable panel.
Acoustic material is vital and we offer a wide range of surface and construction options for banquet room acoustic partition walls to meet any project design and functional standards. Surface treatment options include vinyl, fabric, carpet, veneer, high pressure laminates, frescoes and other custom surfaces – MDF finish can allow customers do surface treatment on site.
The banquet room acoustic partition wall is made of aluminum frame with excellent durability and rigidity in a wide range of challenging applications. From 2 meters to 15 meters high, 4 different thickness of aluminum frames to make sure the durable, safety and reliable operation.
Melamine laminates provide innovative, durable, high-quality finish for acoustic partitions. With more than 200 complete options, including wood grain, pure color, etc.
Acoustic Partitions Application
Our banquet room acoustic partition wall is a movable soundproof room partition system which forms a removable wall. The acoustic partitions are often used to temporarily divide a big room into several small rooms. Unlike other room partition materials, our folding acoustic partitionl has excellent soundproofing performance and they are hanging on an overhead track system.
|Panel suspension||Top hung only||Top hung only||Top hung only|
|Track system||Single or twin point||Single or twin point||Single or twin point|
|Panel thickness||65mm||80mm / 85mm||100mm|
|Panel height||Up to 4000mm||Up to 6000mm||Up to 18000mm|
|Frame construction||Aluminum frame||Aluminum frame||Aluminum frame|
|Face material||9mm||9mm / 12mm||12mm|
|Fire safety||Optional Class I or O||Optional Class I or O||Optional Class I or O|
|Vertical profiles||Aluminum anodised with sealing profiles||Aluminum anodised with sealing profiles||Aluminum anodised with sealing profiles|
|Retractable seals||Aluminum black with
double rubber seals
|Aluminum black with double rubber seals||Aluminum black with double rubber seals|
|Operation of seals||Manual, with supplied
|Manual, with supplied operating handle||Manual, with supplied operating handle|
|Locking||Optional lock to pass doors||Optional lock to pass doors||Optional lock to pass doors|
|Pass doors||Single open in panel or
double open in two panel
|Single open in panel or double open in two panel||Single open in panel or double open in two panel|
|Sound insulation||20-32dB Rw||28-36dB Rw||32-50dB Rw|
|Weight||Approx 22-35kg/sq M||Approx 25-40kg/sq M||Approx30-48kg/sq M|
