|Product Name:||Acoustic Partition Walls||Application:||Banquet Hall Partitions|
|Aluminium Alloy:||6063-T6||Frame Thickness:||65 Mm|
|Function:||Room Divider / Partition||Style:||Modern|
Commercial Conference Hall Movable Acoustic Partition Walls Cost for Dance Studio
Conference hall acoustic partition walls details
Conference hall acoustic partition walls place all options at your fingertips, no matter it’s for room to work or room to play, public meetings or private functions, assembly or seminars, etc. Our conference hall acoustic partition walls can easily slid along a hidden track above the ceiling, providing all the acoustics and aesthetic features of the fixed wall with an immeasurable advantage of maximum flexibility.
You can easily and quickly achieve a variety of configurations and divisions. Once in place, the spring-loaded seal locks like it’s fixed. The fully modular system allows conference hall acoustic partition walls to be designed by project, taking into account all individual needs. The installation can be carried out local installers with our instruction. In essence, our banquet hall partitions can eliminate barriers of your architectural design and take full advantage of your available space.
Conference hall acoustic partition wall is a customizable range of movable partition panels that conforms to the customer’s precise specifications.
As a soundproof operable system, conference hall acoustic partition wall is the best choice for places where noise reduction and space dividing are the primary task.
Conference hall acoustic partition walls installation
1. After the conference hall acoustic partition walls rail is transported to the construction site, the construction personnel should first understand the general decoration style of the site, including the ceiling shape, the ground shape, whether there is a skirt line on the wall, etc., timely communicate with the on-site woodworker, and then release the line to determine the track installation. position;
2. After the horizontal line is placed, the construction side will determine the layout direction of the air-conditioning duct fire-fighting pipe, and it is convenient to determine the steel structure installation form, whether it is a straight pull or a diagonal support or a U-slot fix. These are responsible installation teams. Do the preparation before the construction, otherwise work and do things, when the impact on the site construction layout, but also to rework, seriously affect the construction progress, will also bring unnecessary trouble to Party A;
3. After the conference hall acoustic partition walls tracks are installed, the track level will be self-checked again, and finally the steel structure will be rust-proofed, and then Party A will be notified and the position of the track movable port will be clearly stated. When the ceiling is clearly indicated, it cannot be fixed with the track. Otherwise, loading and unloading The door panel will likely damage the integrity of the ceiling.
|Panel suspension||Top hung only||Top hung only||Top hung only|
|Track system||Single or twin point||Single or twin point||Single or twin point|
|Panel thickness||65mm||80mm / 85mm||100mm|
|Panel height||Up to 4000mm||Up to 6000mm||Up to 18000mm|
|Frame construction||Aluminum frame||Aluminum frame||Aluminum frame|
|Face material||9mm||9mm / 12mm||12mm|
|Fire safety||Optional Class I or O||Optional Class I or O||Optional Class I or O|
|Vertical profiles||Aluminum anodised with sealing profiles||Aluminum anodised with sealing profiles||Aluminum anodised with sealing profiles|
|Retractable seals||Aluminum black with
double rubber seals
|Aluminum black with double rubber seals||Aluminum black with double rubber seals|
|Operation of seals||Manual, with supplied
|Manual, with supplied operating handle||Manual, with supplied operating handle|
|Locking||Optional lock to pass doors||Optional lock to pass doors||Optional lock to pass doors|
|Pass doors||Single open in panel or
double open in two panel
|Single open in panel or double open in two panel||Single open in panel or double open in two panel|
|Sound insulation||20-32dB Rw||28-36dB Rw||32-50dB Rw|
|Weight||Approx 22-35kg/sq M||Approx 25-40kg/sq M||Approx30-48kg/sq M|
