Removable Wall System Operable Acoustic Partition Walls For Conference Hall / Classroom
Product Details:
| Place of Origin: | Guangzhou, China |
| Brand Name: | EBUNGE |
| Certification: | ISO 9001 |
| Model Number: | 85 mm acoustic partition walls |
Payment & Shipping Terms:
| Minimum Order Quantity: | No MOQ, small quantity welcome |
|---|---|
| Price: | $82-98 per square meter. |
| Packaging Details: | Paper carton, outside with wooden box. |
| Delivery Time: | 7-15 days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 50000 square meters per month |
|
Detail Information |
|||
| Product Name: | Acoustic Partition Walls | Application: | Classroom Partition Walls |
|---|---|---|---|
| Material: | MDF + Aluminum | Based Board: | MDF Or Plywood |
| Size: | Partition Walls Customized | Color: | Optional |
| High Light: | acoustic operable wall,movable acoustic partition walls |
||
Product Description
Removable Wall System Operable Acoustic Partition Walls for Conference Hall / Classroom
Acoustic partition walls details
The acoustic partition wall is our individual panel partition system offering an acoustic insulation rating of up to 53 dB.
Ideally suited for high specification applications due to the sheer flexibility, numerous stacking arrangements available and the impressive acoustic qualities this system offers.
The acoustic partition walls panels are operated by means of an internal scissor-jack mechanism and move effortlessly along an aluminium head track, when closed they form a secure fixed wall.
Acoustic partition walls system is a high quality movable wall system to suit timber panels up to 150 kiliograms in weight, there are multiple options for Door types, parking areas and track layouts. Each door is a top hung straight sliding panel which sits inline with the other doors these panels can be moved into a parking area when the wall needs to be opened, pivot panels can be fixed or converted into sliding doors. Acoustic partition walls can be created to suit any space within reason.
Acoustic partition walls offer reliable solutions for your space division requirements. We have been devoted to the act or process of creating quality, functional areas for residential, commercial and industrial applications. The strength of our company is based upon a combination of our 10 years experience, representing established manufacturers committed to quality, an attention to detail, and an installation crew bent on completing the job right and on schedule.
Staying current with the latest architectural and engineering trends as well as a hands on approach from conception to completion has also helped keep clients coming back for more. Give us a call and talk to our professionals about folding walls, accordion doors, roll-up partitions and flexible space design.
Technical information
| Model | BG65 | BG85 | BG100 |
| Suspension System | Hanging System, with ceiling rails | ||
| Basic Thickness | 65mm | 85mm | 100mm |
| Max Height | Max 3800mm | Max 6000mm | Max 8000mm |
| Width | 800 -1230mm | ||
| Floor/ceiling Sealing strength |
Telescopic aluminum tube with rubber strip | ||
| Side Walls Sealing Strength |
Double seal tape | ||
| Base Board Thickness | 9 mm | 9 mm | 12 mm |
| Vertical Profiles | Aluminum anodised with sealing profiles | ||
| Retractable Seals | Aluminum black with double rubber seals | ||
| Operation | Manual System, with supplied operating handle | ||
| Pass Doors | Single or Double Pass Through Door Available | ||
| Weight | Approx 22-35 kg/m² | Approx 25-40 kg/m² | Approx30-48 kg/m² |
| Finish Options | Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized) | ||
Acoustic partition walls features
Top hung system without the need for a floor track.
Retractable top and bottom seals ensure effortless movement of panels.
Concealed or exposed panel edge profiles.
Numerous panel stacking options for complete flexibility.
Extensive range of surface finishes available, easy construction and transportation.
The system offers various levels of sound reduction.
Combines elegance with robust construction.
Improved sound insulation with a reduced wall thickness.
Space savings in the parking area.
Low specific weights with obvious structural advantages.
Our service
A full professional design service.
Survey and installation guide.
Using top quality materials and components.
A fully experienced work team.
Maintenance contracts to ensure your valuable asset remains in full work order.
