Product Details:

Place of Origin: Guangzhou, China
Brand Name: EBUNGE
Certification: ISO 9001
Model Number: 85 mm sound proof partitions

Payment & Shipping Terms:

Minimum Order Quantity: No MOQ, small quantity welcome
Price: $82-98 per square meter.
Packaging Details: Paper carton, outside with wooden box.
Delivery Time: 7-15 days
Payment Terms: T/T, Western Union
Supply Ability: 50000 square meters per month
Get Best Price Contact Now

Detail Information

Product Name: Sound Proof Partitions Application: Conference Hall Partitions
Style: Foldable System: Hanging System
Size: Partition Walls Customized Weight: 25 KG Per Square Meter
High Light:

movable sound proof partitions

,

movable soundproof partition

Product Description

Laminate Operable Foldable Sound Proof Partitions Sliding Movable Walls for Conference Hall



Sound proof partitions details



The sound proof partition is our individual panel partition system offering an acoustic insulation rating of up to 53 dB.


Ideally suited for high specification applications due to the sheer flexibility, numerous stacking arrangements available and the impressive acoustic qualities this system offers.



The sound proof partitions panels are operated by means of an internal scissor-jack mechanism and move effortlessly along an aluminium head track, when closed they form a secure fixed wall.



Sound proof partitions system is a high quality system to suit timber panels up to 150 kilograms in weight, there are multiple options for Door types, parking areas and track layouts. Each door is a top hung straight sliding sound proof partitions panel which sits inline with the other doors these panels can be moved into a parking area when the wall needs to be opened, pivot panels can be fixed or converted into sliding doors. Sound proof partitions can be created to suit any space within reason.

Laminate Operable Foldable Sound Proof Partitions Sliding Movable Walls For Conference Hall 0



Sound proof partitions features



Stable and self-supporting frame construction.


Flexibility through wide variety of panel arrangements.


Ease of use & movement due to lightness in construction.


Smooth and silent while in operation.


Good acoustic performance.


Availability of unlimited choice of finishes.

Laminate Operable Foldable Sound Proof Partitions Sliding Movable Walls For Conference Hall 1



Technical information



Series BG65 BG85 BG100
Panel suspension Top hung only Top hung only Top hung only
Track system Single or twin point Single or twin point Single or twin point
Panel thickness 65mm 80mm / 85mm 100mm
Panel height Up to 4000mm Up to 6000mm Up to 18000mm
Max height 4000mm 6000mm 18000mm
Panel width 600-1230mm 600-1230mm 600-1230mm
Frame construction Aluminum frame Aluminum frame Aluminum frame
Face material 9mm 9mm / 12mm 12mm
Fire safety Optional Class I or O Optional Class I or O Optional Class I or O
Vertical profiles Aluminum anodised with sealing profiles Aluminum anodised with sealing profiles Aluminum anodised with sealing profiles
Retractable seals Aluminum black with
double rubber seals
Aluminum black with double rubber seals Aluminum black with double rubber seals
Operation of seals Manual, with supplied
operating handle
Manual, with supplied operating handle Manual, with supplied operating handle
Locking Optional lock to pass doors Optional lock to pass doors Optional lock to pass doors
Pass doors Single open in panel or
double open in two panel
Single open in panel or double open in two panel Single open in panel or double open in two panel
Sound insulation 20-32dB Rw 28-36dB Rw 32-50dB Rw
Weight Approx 22-35kg/sq M Approx 25-40kg/sq M Approx30-48kg/sq M
Finish Material Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized)

Laminate Operable Foldable Sound Proof Partitions Sliding Movable Walls For Conference Hall 2
