Product Details:

Place of Origin: Guangzhou, China
Brand Name: EBUNGE
Certification: ISO 9001
Model Number: 65 mm sliding partition walls

Payment & Shipping Terms:

Minimum Order Quantity: No MOQ, small quantity welcome
Price: $82-98 per square meter.
Packaging Details: Paper carton, outside with wooden box.
Delivery Time: 7-15 days
Payment Terms: T/T, Western Union
Supply Ability: 50000 square meters per month
Get Best Price Contact Now

Detail Information

Product Name: Sliding Partition Walls Application: Hotel Partition Walls
Sample: Free Based Board: 9 Mm MDF Board
Size: Partition Walls Customized Color: Accept Customized
High Light:

sliding folding partition

,

sound proof sliding partitions

Product Description

Aluminium Track Acoustic Movable Walls Hotel Folding Sliding Partition Walls



Sliding partition walls details



Sliding partition walls system is ideal for dividing and creating rooms. The sliding partition walls system can either be supported from the ceiling and is made up of wall panels that are connected by hinges and stored at the end of the track when opening the wall. There are sound insulation seals between the panels, ceiling and floor.



The sliding partition walls structure is composed of aluminum profiles, sheets of treated particleboard or MDF and insulation. The combined structure forms a panel that has a total thickness of 85 mm and depending on the insulation material ensures a soundproof resistance of 40-49 dB (decibels).



When the sliding partition walls system is supported at the ceiling it runs along an adjustable aluminum upper track that is equipped with bearings inside of carriages. This enables the walls height to be adjusted by 15 mm. The carriages are installed on every second wall panel and are located at the center of the panel. Because the wall hangs from the ceiling, it is important for the installation of the wall that the wall is attached to something solid (i.e. concrete ceiling, steel structure, wood beam etc).



In the case that the sliding partition wall is supported by the ground, an aluminum track is installed on the floor where the carriages move the wall and at the top there is a guiding track. The height is also adjustable by 15 mm.



At the end of the wall, a jamb profile is installed to close the last panel and which is also used as a door. This, together with the jamb is installed to start the wall and allows for the sliding partition walls width to be adjusted 20 mm.

Aluminium Track Acoustic Movable Walls Hotel Folding Sliding Partition Walls 0



Sliding partition walls advantages



Long-term use: with more economy and higher decorative, beautiful and safe, will not scratch the skin.


Cost savings: installation does not affect the construction of smallpox and the ground.


Various forms: optional with a variety of occasions partition wall, can be customized according to customer requirements.


Easy combination: in the re-assembly can make full use of building materials.


Material environmental protection: selection of high-quality melamine particleboard, sound insulation and sealing a good variety of accessories a variety of options.

Aluminium Track Acoustic Movable Walls Hotel Folding Sliding Partition Walls 1



Technical information



Series BG65 BG85 BG100
Panel suspension Top hung only Top hung only Top hung only
Panel thickness 65 mm 85 mm 100 mm
Max height 4000 mm 6000 mm 18000 mm
Panel width 500-1200 mm 500-1200 mm 500-1200 mm
Face material 9 mm 9 mm 12 mm
Pass doors Single door or Double door
Sound insulation 20-32dB Rw 28-36dB Rw 32-50dB Rw



Finish Material

Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized)

Aluminium Track Acoustic Movable Walls Hotel Folding Sliding Partition Walls 2
