Operable Auditorium Sound Proof Floor To Ceiling Movable Partition Walls

Operable Auditorium Sound Proof Floor To Ceiling Movable Partition Walls

Product Details:

Place of Origin: China
Brand Name: Bunge
Model Number: 65 mm Movable Partition

Payment & Shipping Terms:

Minimum Order Quantity: 1 Square Meters
Price: USD 75-95/ Square Meter
Packaging Details: Carton package , Paper package
Delivery Time: 10 working days after received your down payment
Payment Terms: T/T, L/C, Western Union
Supply Ability: 5,000 Square Meters per Month
Get Best Price Contact Now

Detail Information

Product Name: Movable Partition Wall Color: Customized
Material: Wooden Size: Customized
Advantage: Movable ,sliding Application: Office ,hotel
High Light:

movable walls on wheels

,

acoustic movable walls

Product Description

Operable Auditorium Sound proof Floor To Ceiling Movable Partition Wall​



BUNGE movable wall partitions provide a wide range of aesthetic,operational,and performance options and are the perfect solution to meet demanding space flexibility requirements. With over 10 years of acoyustic room dividers expertise, BUNGE movable wall partition has been the exclusive installing distributor of BUNGE movable wall partitions. Our designers can assist you early in your design with layout, structural support and storage pocket requirements, finish options, reliable budgets, and the myriad of other details required to make each application a success. Highlights include:

Product lines
Single, Paired, and continuously hinged panel configurations
Highly customizable finishes including wood veneers, rigidized metals, plastic laminates and more
Flexible storage configurations
Top hung and floor supported systems
Manual and motor-operated systems
Track systems stocked for quick-turn tenant improvement projects
Structural support systems available
In-house factory-certified installers and service techs



Operable Auditorium Sound Proof Floor To Ceiling Movable Partition Walls 0



Series BG 65 BG 85 BG100
Panel supension Top hung only Top hung only Top hung only
Panel thickness 65 mm 85 mm 100 mm
Max height 4000 mm 6000 mm 8000 mm
Panel width 600-1230 mm 600-1230 mm 600-1230 mm
Face material 9 mm 9 mm 9 mm
Pass doors Single Door or Double Door
Sound insulation 20 – 32 db 28 – 36 db 32 – 50 db
Finish Material Plywood / MDF /Laminate / Melamine / Gypsum
Board / Fabric / Insulation / Fireproof /Wall Paper /Vinyl /Painting /etc,(Customized)



Operable Auditorium Sound Proof Floor To Ceiling Movable Partition Walls 1



Application: all products are suitable for hotel, conference room, multi-function hall, exhibition hall, library, museum, culture square, gymnasium, training institution, office, school, KTV, hospital, shopping market, etc



The structure of movable wall partitions



The BUNGE movable wall partitions structure is composed of aluminum profiles, sheets of treated particleboard or MDF and insulation. The combined structure forms a panel that has a total thickness of 82 mm and depending on the insulation material ensures a soundproof resistance of 32-53dB (decibels).
When the acoustic room divider is supported at the ceiling it runs along an adjustable aluminum upper track that is equipped with bearings inside of carriages. This enables the walls height to be adjusted by ±18 mm. The carriages are installed on every second wall panel and are located at the center of the panel. Because the acoustic room dividers wall hangs from the ceiling, it is important for the installation of the wall that the wall is attached to something solid (i.e. concrete ceiling, steel structure, wood beam etc.).
In the case that the folding wall is supported by the ground, an aluminum track is installed on the floor where the carriages move the wall and at the top there is a guiding track. The height is also adjustable by ±18 mm.



Operable Auditorium Sound Proof Floor To Ceiling Movable Partition Walls 2
