Product Details:

Place of Origin: Guangzhou, China
Brand Name: EBUNGE
Certification: ISO 9001
Model Number: 85 mm sound proof partitions

Payment & Shipping Terms:

Minimum Order Quantity: No MOQ, small quantity welcome
Price: $82-98 per square meter.
Packaging Details: Paper carton, outside with wooden box.
Delivery Time: 7-15 days
Payment Terms: T/T, Western Union
Supply Ability: 50000 square meters per month
Get Best Price Contact Now

Detail Information

Product Name: Sound Proof Partitions Application: Conference Room Partitions
Sample: Free Thickness: 85 Mm(3 1/4 Inch)
Function: Soundproof, Fire Proof Size: Customized
High Light:

sounproof folding partition

,

movable sound proof partitions

Product Description

Conference Room Sound Proof Partition Acoustic Room Divider Sliding Movable Partitions

Finished project

Thanks for the trust from a Mexico Client. This sound proof partitions project finished in April.

Application: Function Hall Partitions

Surface: Leather Surface(Soft Cover)

Height: 3200 mm

Width:  9550 mm

Total amount: 30.56 square meters.
Conference Room Sound Proof Partition Acoustic Room Divider Sliding Movable Partitions 0

Conference Room Sound Proof Partition Acoustic Room Divider Sliding Movable Partitions 1
Conference Room Sound Proof Partition Acoustic Room Divider Sliding Movable Partitions 2


Sound proof partitions details


Panel Configuration – The sounnd proof partitions panels are customized to meet specific requirements. Each sound proof partition board thickness is 100mm and max width is 1200mm. Each single room partition wall panel is welded with a welded aluminum frame and 9mm MDF is mounted on both sides of the outer surface. The internal structure is made of steel mechanism, which combines excellent performance at the top and bottom of the telescopic sound seal. Internal space is filled with less than 64 kg/m3 glass wool.



Overhead track system – specific aluminum alloy rails to meet the necessary stacking requirements. The intersection design should prevent the track wheel from falling into the track groove. Heavy-duty multi-way roller enables easy movement of the sliding partitions for rooms through the ceiling track.



The panel of sound proof partitions has a unique fast seal winding mechanism and a solid vertical seal edge profile to ensure that all panels fit perfectly.



Sound Seal System – Built-in excellent retractable top and bottom seals are anodized by extruded aluminum channels, rubber sealed, and operated by a handle with a cap lock system with spring-loaded telescopic rods. The vertical seal of each panel is made of thick and tongue-type extruded aluminum laminated with rubber seal.



Top and bottom seals do not collected to the ceiling track and floor during panel’s movement. When the sound seals are combined, the sound proof partitions panel is placed in a stable position, and the top and bottom seals are compressed on the rails and floors by tight acoustic seals, including adjustable telescopic panels.



Acoustic Rating – Sound proof partitions with high acoustic performance should provide an average sound attenuation of 45Db to 50DB.



Weight – The weight of sound proof partitions panel should be an average of 40 kg/m2, depending on the panel size.



Panel surface – By default it’s 9mm MDF board. However, it can be adapted to any decorative design, such as wood veneer, fabric, etc.



Applications and operations – The soundproof partition walls consist of a series of single flat wall panels that are manually operated and allow stacking flexibility of the center or remote side.

Conference Room Sound Proof Partition Acoustic Room Divider Sliding Movable Partitions 3

Technical information

Model BG65 BG85 BG100 Ultra-high System
Suspension System Hanging System, with ceiling rails
Basic Thickness 65mm 85mm 100mm 100 mm
Max Height Max 3800 mm Max 6000 mm Max 8000 mm Max 15000 mm
Width 800 -1230mm
Floor/ceiling Sealing strength Telescopic aluminum tube with rubber strip

Side Walls Sealing
Strength

Double seal tape
Base Board Thickness 9 mm 9 mm 12 mm 12 mm
Vertical Profiles Aluminum anodised with sealing profiles
Retractable Seals Aluminum black with double rubber seals
Operation Manual System, with supplied operating handle
Pass Doors Single or Double Pass Through Door Available
Weight Approx 22-35 kg/m² Approx 25-40 kg/m² Approx30-48 kg/m² Approx38-68 kg/m²
Finish Options Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized)

Conference Room Sound Proof Partition Acoustic Room Divider Sliding Movable Partitions 4



FAQ



1. Are you a trading company or a factory ?


Our company was established in Guangzhou city, with our own factory in Liwan District. We are a manufacturer engaged in movable partition for more than 10 years. Welcome to pay a visit to our factory in Guangzhou.



2.How can you guarantee the quality?


We provide 5 years warrenty.



3.How to finalize orders?


Please send your room drawing and provide requirements like partition surface finished and soundproof requirements, we will design the partition for free. After your confirmation, we can start production.



4.How long is the lead time.


Normally 10-25 days upon receiving the deposit, base on the quantity 300 SQM



5.Can you do the installation?



Yes, we can send engineer to guide installtion, details please contact us.

6.How is the soundproof quality ?



From 30dB to 55dB, depends of which type and what partition surface finished you need. Contact us and we will provide professional suggestions.
