Aluminum Living Room Design Details Materials Movable Doors Partition Wall
Product Details:
| Place of Origin: | China |
| Brand Name: | Bunge |
| Model Number: | 65 mm Movable Partition |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Square Meters |
|---|---|
| Price: | USD 75-95/ Square Meter |
| Packaging Details: | Carton package , Paper package |
| Delivery Time: | 10 working days after received your down payment |
| Payment Terms: | T/T, L/C, Western Union |
| Supply Ability: | 5,000 Square Meters per Month |
|
Detail Information |
|||
| Product Name: | Movable Partition Wall | Surface: | MDF,Melamine |
|---|---|---|---|
| Color: | Customized | Size: | Customized |
| Finish: | Customized | Drawing: | Free |
| Sample: | Free | ||
| High Light: | movable walls on wheels,acoustic movable walls |
||
Product Description
Aluminum Living Room Design Details Materials Movable Doors Partition Wall
Movable Wall Design
The operable wall series is the highest specification range of fully operable ,individual – panel partition system .Acoustic insulation of up to 55 db noise reduction is achieved with a combination of operable top and bottom seals, high performance multiple infills and a panelassembly design that allows an acoustic break between the frame and outer layer ,The vertical channels of each panel incorporate polymer inserts that facilitate an acoustic seal when the panels are set out as a wall. Panels are produced in four thiknesses ,65mm.85mm,100mm,125mm,depending on acoustic rating (from 32db – 55db )
Technical Details
| Series | BG65 | BG85 | BG100 |
| Panel suspension | Top hung only | Top hung only | Top hung only |
| Panel thickness | 65mm | 85mm | 100mm |
| Max height | 4000mm | 6000mm | 18000mm |
| Panel width | 500-1200 mm | 500-1200 mm | 500-1200 mm |
| Face material | 9mm | 9mm | 12 mm |
| Passdoors | Single door or Double door | ||
| Sound insulation | 28-38dB Rw | 28-42dB Rw | 32-50dB Rw |
| Finish Material | Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc.(Customized) | ||
The characteristic of movable partition
1: Partition products are modern architectural decoration style, space can be quickly separated, easy to use, and with sound insulation, heat insulation function
2: The wallboard is made of high-strength steel framework, soundproof cotton and decorative panels, with smooth board surface and strong collision resistance
3: The wallboard is hoisted by the straight and universal rails embedded in the aluminum alloy track, and the single wheel can rotate 360 degrees and turn 90 degrees. With flexible track trend, suitable for a variety of different storage storage requirements
4: The ground is not laid track, only the track hanging in the ceiling, and decorative ceiling flat;Does not affect the overall continuity of the space, changes in the invisible
5: Wallboard surface can cooperate with a variety of finishes to achieve different decorative effects
Partitions wall usage
Our products (Movable Partitions and Acoustic Panels) are widely used in the hotel banquet halls, meeting rooms, exhibition halls, conference rooms, international convention centers, KTVs, upscale restaurants, office buildings, schools, hospitals auditorium, stadium and so on
