Low Cost Material Folding Cubicle Movable Doors Partition Wall For Banquet Hall
Product Details:
| Place of Origin: | China |
| Brand Name: | Bunge |
| Model Number: | 65 mm Movable Partition |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Square Meters |
|---|---|
| Price: | USD 75-95/ Square Meter |
| Packaging Details: | Carton package , Paper package |
| Delivery Time: | 10 working days after received your down payment |
| Payment Terms: | T/T, L/C, Western Union |
| Supply Ability: | 5,000 Square Meters per Month |
|
Detail Information |
|||
| Product Name: | Movable Partition Wall | Surface: | MDF,Melamine |
|---|---|---|---|
| Application: | Banquet Hall | Material: | Wooden |
| Color: | Customized | Size: | Customized |
| Finish: | Customized | ||
| High Light: | movable walls on wheels,movable partitions systems |
||
Product Description
Low Cost Material Folding Cubicle Movable Doors Partition Wall For Banquet Hall
BUNGE movable wall partitions provide a wide range of aesthetic,operational,and performance options and are the perfect solution to meet demanding space flexibility requirements. With over 10 years of acoyustic room dividers expertise, BUNGE movable wall partition has been the exclusive installing distributor of BUNGE movable wall partitions. Our designers can assist you early in your design with layout, structural support and storage pocket requirements, finish options, reliable budgets, and the myriad of other details required to make each application a success. Highlights include:
- Acousti-Seal and Encore product lines
- Single, Paired, and continuously hinged panel configurations
- Highly customizable finishes including wood veneers, rigidized metals, plastic laminates and more
- Flexible storage configurations
- Top hung and floor supported systems
- Manual and motor-operated systems
- Track systems stocked for quick-turn tenant improvement projects
- Structural support systems available
- In-house factory-certified installers and service techs
Technical Details
| Series | BG65 | BG85 | BG100 |
| Panel suspension | Top hung only | Top hung only | Top hung only |
| Panel thickness | 65mm | 85mm | 100mm |
| Max height | 4000mm | 6000mm | 18000mm |
| Panel width | 500-1200 mm | 500-1200 mm | 500-1200 mm |
| Face material | 9mm | 9mm | 12 mm |
| Passdoors | Single door or Double door | ||
| Sound insulation | 28-38dB Rw | 28-42dB Rw | 32-50dB Rw |
| Finish Material | Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc.(Customized) | ||
The structure of movable wall partitions
The BUNGE movable wall partitions structure is composed of aluminum profiles, sheets of treated particleboard or MDF and insulation. The combined structure forms a panel that has a total thickness of 82 mm and depending on the insulation material ensures a soundproof resistance of 32-53dB (decibels).
When the acoustic room divider is supported at the ceiling it runs along an adjustable aluminum upper track that is equipped with bearings inside of carriages. This enables the walls height to be adjusted by ±18 mm. The carriages are installed on every second wall panel and are located at the center of the panel. Because the acoustic room dividers wall hangs from the ceiling, it is important for the installation of the wall that the wall is attached to something solid (i.e. concrete ceiling, steel structure, wood beam etc.).
In the case that the folding wall is supported by the ground, an aluminum track is installed on the floor where the carriages move the wall and at the top there is a guiding track. The height is also adjustable by ±18 mm.
How to choose the partition walls
First, there are 65-type, 80-type, 85-type, 100-type and ultra-high-type partitions. The general area is small, and the indoor height is less than 3 meters. It is recommended to use 65-type movable partitions, economical, and larger space, like exhibition halls, theaters , Hotel lobby, you can see the situation to choose the thickness and height of the activities of the partition. The designer of Grethes can come to design the material for you. You don't have to worry about it.
In addition, there are also movable wall partition panels. The selection and color of the panel must be the main color of the composite space. There are a variety of styles of decorative partitions, including fabrics, soft leather bags, melamine boards, and wallpaper murals. Each material has hundreds of colors and styles.
