Sliding Folding Acoustic Partition Wall , Commercial Furniture Soundproof Room Divider
Product Details:
| Place of Origin: | China,Guangzhou |
| Brand Name: | BUNGE |
| Certification: | ISO9001 |
| Model Number: | Series 65 mm acoustic partition wall |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 square meters |
|---|---|
| Price: | 85 / 126 dollar per square meter |
| Packaging Details: | Carton package, MDF batten on four section sides ,foam board on both front face. |
| Delivery Time: | Shipped in 10 days after payment, based on the quantity. |
| Payment Terms: | D/A, D/P, L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 5000 square meters per month |
|
Detail Information |
|||
| Product Name: | Acoustic Partition Wall | Function: | Divide Space |
|---|---|---|---|
| Panel Thickness: | 65 Mm | Height: | Less Than 4 M |
| Width: | 800-1300 Mm | Material: | MDF Board+Aluminium |
| Surface: | Melamine,fabric,leather | Open Style: | Folding And Sliding |
| Application: | Conference Hall,meeting Room And Etc | Service: | OEM Service |
| High Light: | acoustic operable wall,movable acoustic partition walls |
||
Product Description
Commercial Furniture Soundproof Room Divider Sliding Folding Acoustic Partition Wall
Specification:
In the past, there are special occasions where a large space was divided into different levels and different specifications. It took a lot of steps to complete the work, and the space that may be distributed sometimes is not particularly reasonable due to technical reasons.
It will be affected, and this problem has been effectively solved since the rise of movable partition wall. The use of movable partition wall to separate the large space and the effect is outstanding, and it is very simple to use, no problem, and its The so-called active partition is the performance of free movement.
Installation movable wall partition is free to place its own position, and unsatisfactory can be properly moved without spending too much time.
Feature:
1. Efficient fire prevention: the material of the movable partition is made of fireproof material and has good fireproof performance;
2.Heat insulation: according to different occupancy rates, the space can be divided into small spaces, and good thermal insulation performance;
3.Sound insulation and environmental protection: its sound insulation coefficient can reach 53dB, sound insulation effect is good;
4.Stable and safe: stable and reliable, not easy to swing, shake;
5.No rail suspension: no need to install the ground rail on the floor, its track is installed on the ceiling.
Acoustic partition wall advantage:
Hinged pair panels for quick and easy operation.
Robust aluminum frame construction for demanding environments.
Room divider wide range of surface finishes.
Partial and fully operating panels available.
Partition divider just only top hung supported without floor track.
Technical information:
| TYPE | BG65 | BG85 | BG100 |
| Panel suspension | Top hung only | ||
| Track system | Single or twin point | ||
| Panel thickness | 65 mm | 85 mm | 100 mm |
| Panel height | Up to 4000mm,heights greater than 3000mm refer to our technical dept. | Up to 6000mm, heights greater than 6000mm refer to our technical dept. Inset passing doors above 2400mm. Full height passing door up to 3000mm high document ‘M’ disabled doors optional. | |
| Max height | 4000mm | 6000mm | 18000mm |
| Panel width |
500 - 1200mm 1' 5/8" -- 4' |
500 - 1200mm 1' 5/8" -- 4' |
500 - 1200mm 1' 5/8" -- 4' |
| Frame | Aluminum | Aluminum | Aluminum |
| Surface material | 9mm | 9mm | 12mm |
| Fire safety | Optional class I | Optional class I | Optional class I |
| Vertical profiles | Aluminum, anodized with sealing profiles, painter optional | Aluminum, anodized with sealing profiles, painter optional | Aluminum, anodized with sealing profiles, painter optional |
| Retractable seals | Aluminum, black with double rubber seals | Aluminum, black with double rubber seals | Aluminum, black with double rubber seals |
| Operation of seals | Manual, with supplied operating handle | ||
| Locking | Optional lock to passing doors | ||
| Passing doors | Single open in one panel or double open in two panel | ||
| Sound insulation | 32-38dB Rw | 36-45dB Rw | 42-55dB Rw |
| Weight | Approx 22-35kg/sq M | Approx 25-40kg/sq M | Approx 30-48kg/sq M |
Acoustic partition wall application:
Increasingly, flexible and efficient space utilization is becoming a must for offices, hotels, exhibition centers, studios and similar. Intelligent solutions are needed that facilitate multifunctional room and etc. You have at your disposal operable partition systems capable of harmoniously combining daylight-flooded and sound insulated room concepts.
We can offer:
1. Profession--We have professional sales staff. Any questions will be replied within 24 hours.
2. Price--Because we are factory , so we can provide higher quality and lower price products.
3 . Service--Easy and convenient to transport,we promise timely delivery date, and good after-sale service.
4. Team--We have our own engineering department, according to your request for your tailor-made for your product.
