Payment & Shipping Terms:
|Product Name:||Sound Proof Partitions||Finished:||Melamine,fabric,leather|
|Thickness:||85 Mm||Height:||Less Than 6 M|
|Width:||800-1200 Mm||Application:||Banquet Hall,hotel,function Room|
|Open Style:||Sliding And Folding||Position:||Commercial|
|Color:||Custom Designed Color||Service:||OEM Service|
|Panel suspension||Top hung only||Top hung only||Top hung only|
|Panel thickness||65 mm||85 mm||100 mm|
|Max height||4000 mm||6000 mm||18000 mm|
|Panel width||500-1200 mm||500-1200 mm||500-1200 mm|
|Face material||9 mm||9 mm||12 mm|
|Pass doors||Single door or Double door|
|Sound insulation||20-32dB Rw||28-36dB Rw||32-50dB Rw|
|Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized)|
Soundproof partition walls are made up of sliding panels which interlock to form a partition wall. This enables you to set up large installations with the minimum amount of effort. When in position the panels have the appearance of a permanent partition wall.
We are in the business of movable wall servicing, movable wall maintenance, movable wall repair and suppliers of acoustic movable walls and sliding folding partitions across England and Wales. We have the knowledge and expertise to service and repair any type of movable walls and folding partitions.
Soundproof partition wall feature:
Easy To move and soundproof
Thanks to the exclusive system: Polymer coated , self-lubricating, wear-resistant ball bearing trolleys.
In its versions, range has undergone the most stringent endurance and mechanical resistance tests in laboratories or in own Test Center. 3-years warranty for parts and labour.
Quick to install
Tool locking of top and bottom rubber seals thanks to a manual system in each panel.
Melamine,plywood,acoustic fabric and leather.
Aluminium profiles that become totally invisible when flat by means of a hollow joint system.
Soundproof wall partition FAQ:
1.How to select the suitable movable wall for your site?
We have 4 types of movable wall, 65 type, 85 type, 100 type and 125 ultra-high type.
You can choose the right movable wall upon the height and soundproof requirement as following.
65 type- Max height: 4000 mm,soundproof:32db to 43 db.
85 type- Max height: 6000 mm,soundproof:38db to 50 db.
100 type- Max height: 9000 mm,soundproof:42db to 55 db.
125 type- Max height: 17000 mm,soundproof:42db to 55 db.
2.What you should do on site?
A beam should built on site for track installation. The minimum distance leaving for track installation from false ceiling to top ceiling is 180 mm.
3.How to install?
We will provide the installation manual and video guiding the installation job.We can also dispatch the installation engineer supervising the installation as request.
4.What is lead time?
The lead time is 7 days to 10 days.
5.How to transport?
Sea transport is a common mode of transportation.In an emergency, can be air freight.
6.How do the goods packing?
Carton paper packaging,MDF batten cover all around corner.
The movable wall panel and track,fittings will be packed separately.
7.What is procurement procedure?
Firstly,send us the shop drawings(if the shop drawing is not available, you can tell us the height from false ceiling to finished floor and width from wall to wall).
Secondly, we offer you the movable wall layout drawings for your confirmation.
Thirdly, we quote the movable wall in accordance with confirmed drawings.
8.What is finishing surface?
The bottom panel is MDF or plywood, which is unfinished face.
You can do decoration on site,such as wallpaper,paint,etc.
We can also provide the product with finished face,such as melamine,veneer,acoustic fabric and leather.
Choose from our stylish fabric or leather covers and have the option to have a soft or hard surface.
We can also provide glass partition for glass clip or aluminium frame panel.
1. Profession--We have professional sales staff. Any questions will be replied within 24 hours.
2. Price--Because we are factory , so we can provide higher quality and lower price products.
3 . Service--Easy and convenient to transport,we promise timely delivery date, and good after-sale service.
4. Team--We have our own engineering department, according to your request for your tailor-made for your product.
