Aluminum Movable Partition Walls For Exhibition Building / Movable Wall Systems
Product Details:
| Place of Origin: | China |
| Brand Name: | Bunge |
| Model Number: | 65 mm Movable Partition |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Square Meters |
|---|---|
| Price: | USD 75-95/ Square Meter |
| Packaging Details: | Carton package , Paper package |
| Delivery Time: | 10 working days after received your down payment |
| Payment Terms: | T/T, L/C, Western Union |
| Supply Ability: | 5,000 Square Meters per Month |
|
Detail Information |
|||
| Product Name: | Movable Partition Wall | Surface: | MDF,Melamine ,Fabric ,Leather |
|---|---|---|---|
| Thickness: | 65 Mm | Sample: | Free |
| Application: | Banquet Hall And Office | Color: | Customized |
| High Light: | movable walls on wheels,acoustic movable walls |
||
Product Description
Aluminum Movable Office mdf Exhibition Material Used Building Partition Wall
Features & Benefits:
>>Panel suspension: Movable, top hung system without the need for a floor track
>>Roller on panel: Single roller or double roller
>>Panel Frames: Heavy-duty steel-gusseted aluminum inner frames reinforced with full height
>>Track: Aluminum track or steel track
>>Top & bottom seals: Top and bottom pressure retractable seals ensure effortless moved and locked.
>>Panel stacking: Numerous panel stacking options for complete flexibility
>>Panel surface: MDF, Plywood, Wall paper, Fabric, Leather, Natural wood veneer, Melamine, Wood moldings, etc.
Operation :
Partitions shall be top supported, manually operated panels stacked in an area nominated in the plans.When closed, the operable wall shall provide a complete sound retardant barrier.No floor track shall be used.
Track :
The tracks are made from extruded 6063 - T6 anodized aluminum .The track housing shall utilize grooves and interlocking steel pins for positive alignment of adjacent track sections , and shall be reinforced overhead by drop rod brackets .Aluminum track housing shall include an integral nut slot to accept a hardened square nut for attaching each drop rod bracket to the top of the track .
Panel Surface Finish :
The panel surface will be as per the clients requirement finished.The basic panels will be raw MDF (the finish materials such as laminate, veneer, melamine or fabric etc.)
Seals :
Vinyl seal of butane rubber will be used as top and bottom and as well as closure seals for the operable wall system.Retractable seal drop will be 22.5mm.
Applications:
Our products (Movable Partitions) are widely used in the hotel banquet halls , meeting rooms , exhibition halls , conference rooms , International Convention Centers , KTVs , upscale restaurants , office buildings , schools , hospitals and others .
Folding style of movable partition walls
The folding style is flexible. According to actual sites, it can design the sapce more reasonable. With controlling the wheelbase skillful, it can make the partition orderly.
| Series | BG 65 | BG 85 | BG100 |
| Panel supension | Top hung only | Top hung only | Top hung only |
| Panel thickness | 65 mm | 85 mm | 100 mm |
| Max height | 400 mm | 600 mm | 800 mm |
| Panel width | 600-1230 mm | 600-1230 mm | 600-1230 mm |
| Face material | 9 mm | 9 mm | 9 mm |
| Pass doors | Single Door or Double Door | ||
| Sound insulation | 20 – 32 db | 28 – 36 db | 32 – 50 db |
| Finish Material | Plywood / MDF /Laminate / Melamine / Gypsum | ||
| Board / Fabric / Insulation / Fireproof /Wall Paper /Vinyl /Painting /etc,(Customized) | |||
