Acoustic Movable Doors Wooden Soundproof Folding Partition Walls For Restaurant
Product Details:
| Place of Origin: | China |
| Brand Name: | Bunge |
| Model Number: | 65 mm Movable Partition |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Square Meters |
|---|---|
| Price: | USD 75-95/ Square Meter |
| Packaging Details: | Carton package , Paper package |
| Delivery Time: | 10 working days after received your down payment |
| Payment Terms: | T/T, L/C, Western Union |
| Supply Ability: | 5,000 Square Meters per Month |
|
Detail Information |
|||
| Product Name: | Movable Partition Wall | Surface: | MDF,Melamine ,Fabric ,Leather |
|---|---|---|---|
| Pass Door: | Can Make | Service: | OEM ODM |
| Application: | Office, Church，Auditorium，banquet Hall,hotel | Drawing: | Free |
| High Light: | movable walls on wheels,movable partitions systems |
||
Product Description
Acoustic Movable Doors Wooden Soundproof Folding Partition Walls For Restaurant
Finished Project
Thanks for the trust from the client. We finished the packing and shipped to agent's warehouse on March 4th,2019.
This is a project in Lebanon,8 meters height partitions,using the steal materials,including the steel tracks,the steel rollers and the steel haging clips.
Totally around 480 square meters.
Actually our steel system can support 900 KG materials,so that is enough to support the panels for this project.
Do you still worry about the installtion? Please do not worry,our professional team can help you about that.
For this project,we just delivered the accessories yesterday by air, and we will send our engineer(Mr. Zeng) to Lebanon to supervise the installation.
Technical Details
| Series | BG65 | BG85 | BG100 |
| Panel suspension | Top hung only | Top hung only | Top hung only |
| Panel thickness | 65mm | 85mm | 100mm |
| Max height | 4000mm | 6000mm | 18000mm |
| Panel width | 500-1200 mm | 500-1200 mm | 500-1200 mm |
| Face material | 9mm | 9mm | 12 mm |
| Passdoors | Single door or Double door | ||
| Sound insulation | 28-38dB Rw | 28-42dB Rw | 32-50dB Rw |
| Finish Material | Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc.(Customized) | ||
Product description
- Extensive worldwide sales network that has proved that our operable partition walls work well worldwide.
- Technical advice or design is available, no matter where you located.
- Integrated space management and acoustic product solutions that can be more profitable and economical to use in your building environment.
- From your first query to the completion of the project, we are here to support.
- Based on years of experience in architectural and design challenges, provide industry-leading technology to solve your space problems.
- Unique custom applications that is flexible enough to meet the needs of any customer
The structure of movable wall partitions
The BUNGE movable wall partitions structure is composed of aluminum profiles, sheets of treated particleboard or MDF and insulation. The combined structure forms a panel that has a total thickness of 82 mm and depending on the insulation material ensures a soundproof resistance of 32-53dB (decibels).
When the acoustic room divider is supported at the ceiling it runs along an adjustable aluminum upper track that is equipped with bearings inside of carriages. This enables the walls height to be adjusted by ±18 mm. The carriages are installed on every second wall panel and are located at the center of the panel. Because the acoustic room dividers wall hangs from the ceiling, it is important for the installation of the wall that the wall is attached to something solid (i.e. concrete ceiling, steel structure, wood beam etc.).
In the case that the folding wall is supported by the ground, an aluminum track is installed on the floor where the carriages move the wall and at the top there is a guiding track. The height is also adjustable by ±18 mm.
How to choose the partition walls
First, there are 65-type, 80-type, 85-type, 100-type and ultra-high-type partitions. The general area is small, and the indoor height is less than 3 meters. It is recommended to use 65-type movable partitions, economical, and larger space, like exhibition halls, theaters , Hotel lobby, you can see the situation to choose the thickness and height of the activities of the partition. The designer of Grethes can come to design the material for you. You don't have to worry about it.
In addition, there are also movable wall partition panels. The selection and color of the panel must be the main color of the composite space. There are a variety of styles of decorative partitions, including fabrics, soft leather bags, melamine boards, and wallpaper murals. Each material has hundreds of colors and styles.
