Movable Partition Wood Folding Acoustic Partition Wall For Conference Hall Decoration
Product Details:
| Place of Origin: | Guangzhou, China |
| Brand Name: | EBUNGE |
| Certification: | ISO9001 |
| Model Number: | 85 mm acoustic partition walls |
Payment & Shipping Terms:
| Minimum Order Quantity: | No MOQ, small quantity welcomed |
|---|---|
| Price: | US $85-102 per square meter |
| Packaging Details: | Paper carton, outside with wooden boxes |
| Delivery Time: | 12-20 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 50000 square meters per month |
|
Detail Information |
|||
| Product Name: | Acoustic Partition Walls | Application: | Office Partition Walls |
|---|---|---|---|
| Size: | Partition Walls Customized | Height: | 2 - 4 Meters |
| Thickness: | 85 Mm(3 1/4 Inch) | Sample: | Free |
| High Light: | acoustic operable partitions,acoustic operable wall |
||
Product Description
Office Decoration Movable Partition Wood Folding Acoustic Partition Wall for Conference Hall
Finished project
Thanks for the trust from the client. We finished the packing and shipped to agent's warehouse on March 4th,2019.
This is a project in Lebanon, using the steal materials,including the steel tracks,the steel rollers and the steel haging clips. 8 meters height partitions, 30 meters width, totally 2 sets of walls, around 480 square meters. We just delivered the accessories by air, and we have sent our engineer(Mr. Zeng) to Lebanon to supervise the installation.
Actually our steel system can support 900 KG materials,so that is enough to support the panels for this project.
Do you still worry about the installtion? Please feel free to contact us for more details, our professional team can help you about that.
|
|
Acoustic partition walls technical details
| Model | BG65 | BG85 | BG100 |
| Suspension system | Aluminum hanging | Aluminum hanging | Aluminum hanging |
| Basic thickness | 65mm | 85mm | 100mm |
| Total thickness | 65/75/85/95mm | 80/90/100/110mm | 100/120/130mm |
| Max height | Up to 3800mm | Up to 6000mm | Up to 8000mm |
| Width | 600-1230mm | 600-1230mm | 800-1230mm |
|
Floor/ceiling sealing strength |
Telescopic aluminum tube with rubber strip | ||
|
Side walls sealing strength |
Double seal tape | ||
| Sound insulation level | 26dB-30dB | 28dB-34dB | 32-40dB |
Acoustic partition walls features
◆ Junction of acoustic partition walls modules meet requirements for corner, three or four way abutments.
◆ The acoustic partition wall is a hanging system.Top hung without track at floor level.
◆ Retractable acoustic seals at top and bottom, operated either by quick release handle or semi-automatically with electronic controls.
◆ Acoustic partition walls panel finishes include vinyl, veneer, melamine laminate, a magnetic dry wipe enamelled writing surface or paint.
◆ Single or two point suspension for centre or remote parking options.
◆ The acoustic partition walls are made of high quality 6063-T5 aluminum materials,all of them are strong and wear resistant.
We Offer:
A full professional design service.
Survey and installation guide.
Using top quality materials and components.
A fully experienced work team.
Maintenance contracts to ensure your valuable asset remains in full work order.
