Aluminium Frame Sliding Folding Wooden Banquet Hall Partition Soundproof Movable Walls for Restaurants
Product Details:
| Place of Origin: | Guangzhou, China |
| Brand Name: | EBUNGE |
| Certification: | ISO9001 |
| Model Number: | 85 mm movable partition walls |
Payment & Shipping Terms:
| Minimum Order Quantity: | No MOQ, small quantity welcomed |
|---|---|
| Price: | US $85-102 per square meter |
| Packaging Details: | Paper carton, outside with wooden boxes |
| Delivery Time: | 12-20 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 50000 square meters per month |
|
Detail Information |
|||
| Product Name: | Movable Partition Walls | Application: | Banquet Hall Partitions |
|---|---|---|---|
| Size: | Partition Walls Customized | Height: | 2 - 4 Meters |
| Thickness: | 85 Mm(3 1/4 Inch) | Frame: | Aluminum Frame |
| High Light: | movable walls on wheels,acoustic movable walls |
||
Product Description
Aluminium Frame Sliding Folding Wooden Banquet Hall Partition Soundproof Movable Walls for Restaurants
Movable partition walls technical details
| Series | BG65 | BG85 | BG100 |
| Panel suspension | Top hung only | Top hung only | Top hung only |
| Track system | Single or twin point | Single or twin point | Single or twin point |
| Panel thickness | 65mm | 80mm / 85mm | 100mm |
| Panel height | Up to 4000mm | Up to 6000mm | Up to 18000mm |
| Max height | 4000mm | 6000mm | 18000mm |
| Panel width | 600-1230mm | 600-1230mm | 600-1230mm |
| Frame construction | Aluminum frame | Aluminum frame | Aluminum frame |
| Face material | 9mm | 9mm / 12mm | 12mm |
| Fire safety | Optional Class I or O | Optional Class I or O | Optional Class I or O |
| Vertical profiles | Aluminum anodised with sealing profiles | Aluminum anodised with sealing profiles | Aluminum anodised with sealing profiles |
| Retractable seals | Aluminum black with double rubber seals |
Aluminum black with double rubber seals | Aluminum black with double rubber seals |
| Operation of seals | Manual, with supplied operating handle |
Manual, with supplied operating handle | Manual, with supplied operating handle |
| Locking | Optional lock to pass doors | Optional lock to pass doors | Optional lock to pass doors |
| Pass doors | Single open in panel or double open in two panel |
Single open in panel or double open in two panel | Single open in panel or double open in two panel |
| Sound insulation | 20-32dB Rw | 28-36dB Rw | 32-50dB Rw |
| Weight | Approx 22-35kg/sq M | Approx 25-40kg/sq M | Approx30-48kg/sq M |
| Finish Material | Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized) | ||
Movable partition walls features
1)Soundproof partition movable walls interlocking male / female trapezoidal vertical aluminium profiles, for soundproof connection between elements.
2)Movable partition wall to ensure additional friction connection, shall be integrated with magnetic strip.
3)Folding partition movable wall is easy element adjustment after installation.
4)Movable wall track system shall be Extruded aluminium, maintenance free with heavy-duty ball bearing steel rollers.
5)Movalbe wall customized support and welcome.
We Offer:
A full professional design service.
Survey and installation guide.
Using top quality materials and components.
A fully experienced work team.
Maintenance contracts to ensure your valuable asset remains in full work order.
Movable partition walls FAQ
How to select the suitable movable wall for your site?
We have 5 types of movable wall , 65type , 85type , 100type and 125 ultra-high type . You can choose the right
movable wall upon the Height and Soundproof requirement as following,
65 type— Max height 3.5m, soundproof: 22dB to 32dB
85 type— Max height:5.5m,Soundproof: 28dB to 38dB
100 type— Max height:7m,Soundproof: 43dB to 48dB
125ultra-height — Max height:17m,Soundproof : 45dB to 55dB
What you should do on site ?
A beam(truss) should built on site for track installation . The min distance leaving for track installation from false
ceiling to top ceiling is 200mm .
How to install ?
We will provide the installation manual and video guiding the installation job . We can also dispatch the installation
engineer supervising the installation as request .
What is lead time ?
The lead time is 7 days to 10 days .
How to transport ?
Sea transport is a common mode of transportation. In an emergency, can be air freight.
How do the goods packing ?
Corrugating paper packaging, MDF batten cover all around corner.
The movable wall panel and track, fittings will be packed separately .
What is Procurement procedure ?
Firstly , send us the shop drawings(if the shop drawings is not available , you can tell us the height from false ceiling
to finished floor and width from wall to wall).
Secondly , we offer you the movable wall layout drawings for your confirmation.
Thirdly , we quote the movable wall in accordance with confirmed drawings.
