Wood Fiber Board Ceiling Folding Partition Wall Interior Decorative
Product Details:
Place of Origin: | China |
Brand Name: | Bunge |
Model Number: | 85 mm Movable Partition |
Payment & Shipping Terms:
Minimum Order Quantity: | 1 Square Meters |
---|---|
Price: | USD 75-95/ Square Meter |
Packaging Details: | Carton package , Paper package |
Delivery Time: | 10 working days after received your down payment |
Payment Terms: | T/T, L/C, Western Union |
Supply Ability: | 5,000 Square Meters per Month |
Detail Information |
|||
Product Name: | Movable Partition Wall | Surface: | Melamine,fabric |
---|---|---|---|
Drawing: | Free | Sample: | Free |
Thickness: | 85 Mm | Usage: | Banquet Hall And Office |
High Light: | movable walls on wheels,acoustic movable walls |
Product Description
Interior Decorative Wood Fiber Board Ceiling Acoustic Foldable Wall Partition Panel
(1).Horizontal seals
The principle of double skin construction on movable and operable partition system is applied consistently in the seal area in order to ensure maximum sound insulation . A spindle mechanism presses extendable, spring loaded, double seals against the fl oor and the ceiling track . Any irregularities in the fl ooring are offset by spring-loaded double chamber seals . The contact force of the sealing strips does not place excessive strain on screed floors , but does ensure that the Variflex system is sufficiently stable to prevent the panels moving , even in the event of an attempted forced entry .
(2).Corner seals
Variflex resolves the technical issue of corner seals with specially designed, corner pieces that also reinforce the stability and sound insulation properties of movable and operable partition system
(3)Magnetic strip
The individual panels are centred via the magnetic strips to guarantee sound positive locking and sealing.
Applications :
Our products (Movable Partitions) are widely used in the hotel banquet halls , meeting rooms , exhibition halls , conference rooms , International Convention Centers , KTVs , upscale restaurants , office buildings , schools , hospitals and others .
Bunge aluminium movable partition wall and operable partition wall acoustic movable partition for convention & exhibition centre ( used office room dividers , wood partition , movable wall , restaurant partitions , soundproof folding partition , moveable partition , wall partition , living room partition wall, sandwich panel price, accordion wall , economic partition walls , folding wall, foldable partition wall, folding partition wall , movable sound proof partition , removable wall partition , folding partition , removable partition , partition, partition wall, room divider , room dividing partition , office partition , folding partition wall panel , folding wall panel , folding wall systems )
Technical Details
Series | BG65 | BG85 | BG100 |
Panel suspension | Top hung only | Top hung only | Top hung only |
Panel thickness | 65mm | 85mm | 100mm |
Max height | 4000mm | 6000mm | 18000mm |
Panel width | 500-1200 mm | 500-1200 mm | 500-1200 mm |
Face material | 9mm | 9mm | 12 mm |
Passdoors | Single door or Double door | ||
Sound insulation | 28-38dB Rw | 28-42dB Rw | 32-50dB Rw |
Finish Material | Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc.(Customized) |
