Modern Office Sliding Folding Partition Wall , Acoustic Room Divider
Product Details:
| Place of Origin: | China,Guangzhou |
| Brand Name: | BUNGE |
| Certification: | ISO9001 |
| Model Number: | Series 85 mm folding wall partition |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10 square meters |
|---|---|
| Price: | 85 / 128 dollar per square meter |
| Packaging Details: | Carton package, MDF batten on four section sides ,foam board on both front face. |
| Delivery Time: | Shipped in 10 days after payment, based on the quantity. |
| Payment Terms: | D/A, D/P, L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 5000 square meters per month |
|
Detail Information |
|||
| Product Name: | Folding Partition Wall | Thickness: | 85 Mm |
|---|---|---|---|
| Height: | Less Than 6 M | Application: | Training Room,classroom And Etc |
| Finished: | Melamine,plywood,mdf Board | Open Style: | Sliding And Folding |
| Style: | Modern | Service: | OEM Service |
| Color: | Multi Color | ||
| High Light: | acoustic folding partition,folding room partitions |
||
Product Description
Soundproof Material Acoustic Room Divider Office Sliding Folding Wall Partition
Specification:
The folding partition wall is also called soundproof partition, removable partition, and track partition. The mobile partition has the characteristics of easy installation, reliability, industrial production, fire prevention and environmental protection.
Folding partitions bring great convenience to people's work. For example, the active screen, you can fold it aside when you need it, so that the two spaces are temporarily joined together to make it bigger and convenient for temporary departmental meetings. These products use a ceiling track system that is as strong as a wall.
Feature:
Maximize Your Space.
Folding partition walls provide a simple and cost-effective way of generating space.
We have installed them in a wide range of commercial and public sector environments including offices, exhibition halls, and conference areas.
Quick to install and easy to operate, moveable walls are popular and functional.
They maximize space and versatility in the workplace and provide powerful acoustic and fire performance, whilst seamlessly blending into your interior design thanks to a huge variety of possible finishes.
Folding partition wall advantage:
Top hung with no floor track.
Scissor-jack operating mechanism.
Available with virtually any surface finish.
Ideal for conference centers, hotels, offices & schools.
Angled, glazed, corner or junction panels for maximum flexibility.
Single or double point suspension for versatile stacking options.
Panels with hinged pass door, single or double leaf inset pass door panels for access through.
Application:
Movable partition wall is mainly using in multi function hall,banquet hall,laboratory,classroom, conference room,gymnasium,convention hall,
kindergarten,art gallery,restaurant,meeting room,ballroom and etc.
Technical information:
| Series | BG65 | BG85 | BG100 |
| Panel suspension | Top hung only | Top hung only | Top hung only |
| Track system | Single or twin point | Single or twin point | Single or twin point |
| Panel thickness | 65mm | 80mm / 85mm | 100mm |
| Panel height | Up to 4000mm | Up to 6000mm | Up to 18000mm |
| Max height | 4000mm | 6000mm | 18000mm |
| Panel width | 600-1230mm | 600-1230mm | 600-1230mm |
| Frame construction | Aluminum frame | Aluminum frame | Aluminum frame |
| Face material | 9mm | 9mm / 12mm | 12mm |
| Fire safety | Optional Class I or O | Optional Class I or O | Optional Class I or O |
| Vertical profiles | Aluminum anodised with sealing profiles | Aluminum anodised with sealing profiles | Aluminum anodised with sealing profiles |
| Retractable seals | Aluminum black with double rubber seals |
Aluminum black with double rubber seals | Aluminum black with double rubber seals |
| Operation of seals | Manual, with supplied operating handle |
Manual, with supplied operating handle | Manual, with supplied operating handle |
| Locking | Optional lock to pass doors | Optional lock to pass doors | Optional lock to pass doors |
| Pass doors | Single open in panel or double open in two panel |
Single open in panel or double open in two panel | Single open in panel or double open in two panel |
| Sound insulation | 20-32dB Rw | 28-36dB Rw | 32-50dB Rw |
| Weight | Approx 22-35kg/sq M | Approx 25-40kg/sq M | Approx30-48kg/sq M |
| Finish Material | Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized) | ||
Folding partition wall more details:
1.The folding partition can not be hit with sharp objects, and then move gently when moving, not too hard. For example, if you suddenly get stuck during the movement, then it may be stuck. You should stop moving immediately, then check where the problem occurs and solve the repair in time.
2.The side of the folding partition can not put some flammable items, like chemical dangerous goods. Because some movable partitions are not fireproof, their surfaces are only packaged in soft packs. These soft packs can easily cause fire if exposed to an open flame. Therefore, a fire extinguisher should be placed next to the partition.
3.Folding partition in the daily use should pay attention to maintenance, such as failure can not be removed to repair, but also can not damage the telescopic components inside, if you encounter problems, you should contact the manufacturer for repair or replacement. Secondly, it should be used normally when using the partition, and it can not be used irregularly. It is easy to cause malfunction or damage if it is not used.
