Retractable System Soundproof Sliding Partition Walls / Operable Wall Systems For Classroom
Product Details:
| Place of Origin: | China,Guangzhou |
| Brand Name: | BUNGE |
| Certification: | ISO9001 |
| Model Number: | Series 65 mm sliding partition wall |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10 square meters |
|---|---|
| Price: | 86 /124 dollar per square meter |
| Packaging Details: | Carton package, MDF batten on four section sides ,foam board on both front face. |
| Delivery Time: | Shipped in 10 days after payment, based on the quantity. |
| Payment Terms: | D/A, D/P, L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 5000 square meters per month |
|
Detail Information |
|||
| Product Name: | Sliding Partition Wall | Application: | Classroom,training Room |
|---|---|---|---|
| Thickness: | 65 Mm | Height: | Less Than 4 M |
| Material: | Aluminium Frame And Mdf Board | Service: | OEM Service |
| Open Style: | Sliding And Folding | Surface: | Melamine,leather, Fabric |
| High Light: | sliding folding partition,sound proof sliding partitions |
||
Product Description
Retractable System Soundproof Partitions Sliding Operable Wall System for Classroom
Description:
Our sliding partition system accessories are custom for each client and project,and they are also made of superior material.Track system for right-angled configurations with cross- roller carriers for element weights up to 500 kg. Support rollers in the junctions guarantee easy operation when sliding the elements across intersections .
Besides the high sound absorbing test,we have passed the Eco-protection test and Fireproof test,to ensure you to get the top quality product, and enjoy a safe , comfortable and low carbon emission way of life on movable and operable partition system.
Technical information:
| Series | BG65 | BG85 | BG100 |
| Panel suspension | Top hung only | Top hung only | Top hung only |
| Panel thickness | 65 mm | 85 mm | 100 mm |
| Max height | 4000 mm | 6000 mm | 18000 mm |
| Panel width | 500-1200 mm | 500-1200 mm | 500-1200 mm |
| Face material | 9 mm | 9 mm | 12 mm |
| Pass doors | Single door or Double door | ||
| Sound insulation | 20-32dB Rw | 28-36dB Rw | 32-50dB Rw |
|
Finish Material |
Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized) | ||
Feature:
Individual panels that can be stored away for Maximum space usage.
Operable top and bottom seals for effortless operation.
Aluminum frame construction for enhanced acoustics.
The system offers various levels of sound reduction.
Unique track and carrier system ensuring quiet and easy operation.
Numerous panel stacking options for complete flexibility.
Top hanging and no floor track.
Extensive range of surface finishes can be available.
Advantage:
Sliding wall partition is a kind of facility with very good sound insulation, because the number can indicate how good its sound insulation is, that is, its sound insulation coefficient can reach 53 dB. Not only that, but it also has very good environmental effects. We are now paying attention to environmental protection. Our environment needs everyone to protect it. Therefore, most people will choose and trust environmentally friendly products because they are not environmentally friendly. This is also very good for our body.
On the other hand it is that our partitions have a very good thermal insulation effect, which gives us the same effect as a solid wall. We can enjoy this product with great confidence, and it can make our life very convenient. The main purpose of the active partition is to divide a large space into a lot of small spaces, or to turn a small space into a large space. So it is just like an activity wall, it has a role of multi-purpose.
Installing details:
1. Remember that the track should be loose enough above all the brackets to ensure that the track is paused;
2. After the track of the movable partition is laid, tighten the connection of all the tracks and adjust the horizontal level of the track correctly. The direction of the track installation must also be horizontal and straight;
3. When the track facility is installed, the sound insulation and mineral wool are the necessary plates for installation;
4. Before closing the movable partition, the height of the carrier must be adjusted, and the straight angle of the track should be checked to make the track partition work well;
5. Check all active partitions, whether they are all vertical, if there is no damage, you can enter the edge of the aluminum frame of the rubber seal vertically and not bend;
If the orbital direction is horizontal, but the active partition is suspended, then the carrier height must be adjusted.
