Decorative Material Sliding Folding Partition Movable Wall Systems For Conference Room
Product Details:
| Place of Origin: | China,Guangzhou |
| Brand Name: | BUNGE |
| Certification: | ISO9001 |
| Model Number: | Series 65 mm movable wall partition |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10 square meters |
|---|---|
| Price: | 85 / 136 dollar per square meter |
| Packaging Details: | Carton package, MDF batten on four section sides ,foam board on both front face. |
| Delivery Time: | Shipped in 10 days after payment, based on the quantity. |
| Payment Terms: | D/A, D/P, L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 5000 square meters per month |
|
Detail Information |
|||
| Product Name: | Movable Wall Partition | Thickness: | 65 Mm |
|---|---|---|---|
| Panel Height: | Less Than 4 M | Function: | Soundproof |
| Application: | Conference Room,classroom And Etc | Service: | OEM Service |
| Color: | Multi Color | Warranty: | 5-10 Years |
| High Light: | movable partitions systems,acoustic movable walls |
||
Product Description
Decorative Material Sliding Folding Partitions Movable Walls for Conference Room
Description:
Acoustic Operable Walls / Movable Partition Systems offer a unique facility for utilising available space in the most practical manner.
They allow a large space to be converted into smaller, separate areas, which can be converted back to a large space with the minimum of effort. Handled well and serviced regularly, they will give many years of trouble free service.
Operable Wall can source, install and maintain a wide range of Operable Walls , Moveable Partitions, Sliding Door Systems and Room Dividers from the top manufacturers and extremely competitive rates.
All installations include initial requirement assessment, on-site training in use and care as well as optional maintenance servicing contracts.
Feature:
Due to the movable partition walls flexibility and cost effectiveness, it allows large rooms to be conveniently sub-divided to maximize space utilization.
Operable wall material is customized built to suit the specified requirement. Movable partition system can be made from aluminium, gypsum, MDF, melamine-faced particleboard, plasterboard, plastic, PVC, softwood, stainless steel or wood veneer.
Technical information:
| Panel Suspension | Top hanging system without the need for a floor track. |
| Panel Width | Each panel 600mm-1200mm. |
| Track | Aluminum Or Steel Track |
| Roller on panel | Single or Double Roller |
| Panel Frames | Heavy-duty steel-gusseted aluminum inner frames reinforced with full height. |
| Top and bottom seals | Top and bottom pressure retractable seals ensure effortless moved and locked. |
| Module | 700mm - 1200mm maximum. |
| Panel stacking | Numerous panel stacking options for complete flexibility. |
| Panel Surface | MDF,Plywood, woven fabric, Leather,Natural wood veneer, Melamine,Wood moldings, etc. |
| Finishes | Satin anodized or polyester powder coating to all exposed aluminium components available in a wide range of colour as standard. |
Sliding aluminium track system:
1. Remember that the rails are loose enough on all brackets. Guaranteed track pause time.
2. Tighten all rail connections and adjust the rail height correctly. The rail mounting direction must also be straight and horizontal.
3. In the installation of track facilities, sound insulation and mineral wool are necessary for installation.
4. There are "L", "T" and "Ten" spurs for the track. There are left and right points for the connection of the steering. It is generally not recommended to use the "10" spur. L and T are trimmed to their corresponding size, and their position is indicated by a numerical marker.
Movable Partition Wall Installing:
1. Before the renovation, the on-site measurement must be performed. According to the measurement data and the construction structure of the site, the design drawings shall be issued by the construction party, and the two parties shall confirm to enter the next step without any doubt.
2. Partition production is usually completed by a design company in its own factory. The installation engineering part is produced on site. Therefore, after confirming the design drawings, the requirements for glass thickness, materials, hardware accessories, and borders shall be analyzed and explained.
3. Pay attention to the strong and weak power engineering during construction, because he not only concerns the installation and wiring of the company's supporting facilities in the future, so he must find a professional qualified cabling company, and have professional and technical personnel to carefully measure the construction site, and then All the drawings on the drawings show the status of reserved switches, sockets, and the direction of various lines.
4. When installing the active partition, be sure to pay attention to the configuration of the air conditioner's reasonable position, especially the central air conditioner. Special attention must be paid to keeping the air outlet and return air outlet in each functional area.
5.Should pay attention to safety measures, such as the layout of the necessary fire protection measures and the overall style of the mix, so as to use the active partition to create a modern and beautiful new urban office trends.
