|Thickness:||65 Mm||Material:||MDF Board+Aluminium Frame|
|Height:||Less Than 4 M||Service:||OEM Service|
|Application:||Classroom,conference Room,office And Etc.||Panel Style:||Modern Style|
|Open Style:||Sliding And Folding||Surface:||Melamine,fabric,leather,plywood|
The basic production material of sliding wall partition is mdf board panel and soundproof rock wool, so it has a good sound-absorbing effect, which is what most customers pursue, because everyone likes to live and work in a quiet environment, and use the activity partition as a segmentation.
The sliding partition wall can satisfy this problem. Different employees of the company need to work in different environments and the activities can solve this problem. It can effectively divide and make the space look more complete, which is the first choice for the company's decoration.
Top hung system without the need for a floor track.
Retractable top and bottom seals ensure effortless movement of panels.
Concealed or exposed panel edge profiles.
Numerous panel stacking options for complete flexibility.
Extensive range of surface finishes available, easy construction and transportation.
The system offers various levels of sound reduction.
Combines elegance with robust construction.
Improved sound insulation with a reduced wall thickness.
Divide the whole area into a number of rooms.
Provide privacy to the inmates from sight and sound.
Are fashionable in design, sizes and finishes customization.
Occupy lesser area.
Ceiling tracks, no floor track.
Sliding and folding.
Easily operate by manual in any position.
1. Before the installation of the movable partition, check the track on which the track parts are assembled on the floor in order;
2. Mark the track line and the mounting bracket at a specific location;
3. Install the movable partition rail bracket to the ceiling;
4. Check whether the movable partition is firmly fixed on the rail. When the rail and the bracket must be loosely stored in the storage area, the bracket plate can be moved to other places;
5.The appropriate position of the storage track is measured before the facility of the main track. This is very important for the placement of intersections in order to continue the installation of the following active partitions;
The operable wall structure is composed of aluminum profiles, sheets of treated particleboard or MDF and insulation. The combined structure forms a panel that has a total thickness of 65/85/100 mm and depending on the insulation material ensures a soundproof resistance of 32-53 dB (decibels).
When the operable folding wall system is supported at the ceiling it runs along an adjustable aluminum upper track that is equipped with bearings inside of carriages. This enables the walls height to be adjusted by 15 mm. The carriages are installed on every second wall panel and are located at the center of the panel. Because the wall hangs from the ceiling, it is important for the installation of the wall that the wall is attached to something solid (i.e. concrete ceiling, steel structure, wood beam etc.).
In the case that the folding wall is supported by the ground, an aluminum track is installed on the floor where the carriages move the wall and at the top there is a guiding track. The height is also adjustable by 15 mm.
|Panel suspension||Top hung only||Top hung only||Top hung only|
|Panel thickness||65 mm||85 mm||100 mm|
|Max height||4000 mm||6000 mm||18000 mm|
|Panel width||500-1200 mm||500-1200 mm||500-1200 mm|
|Face material||9 mm||9 mm||12 mm|
|Pass doors||Single door or Double door|
|Sound insulation||20-32dB Rw||28-36dB Rw||32-50dB Rw|
|Finish Material||Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc.|
We offer quality, reliable solutions with partitions and moveable walls (solid or glass) and accordion doors, security grilles, and wood roll-up doors and shutters. We provide pricing, technical assistance, installation and design options for General Contractors, Architects, and Interior Designers.
