Sliding Aluminium Roller Soundproof Partition Wall Melamine Surface 4m Height
Product Details:
| Place of Origin: | China,Guangzhou |
| Brand Name: | BUNGE |
| Certification: | ISO9001 |
| Model Number: | Series 65 mm sound proof partitions |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10 square meters |
|---|---|
| Price: | 85 /131 dollar per square meter |
| Packaging Details: | Carton package, MDF batten on four section sides ,foam board on both front face. |
| Delivery Time: | Shipped in 10 days after payment, based on the quantity. |
| Payment Terms: | D/A, D/P, L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 5000 square meters per month |
|
Detail Information |
|||
| Finished: | Melamine,fabric,leather | Height: | Less Than 4 M |
|---|---|---|---|
| Thickness: | 65 Mm | Width: | 500-1300 Mm |
| Application: | Conference Room,classroom And Etc | Product Name: | Sound Proof Partitions |
| Color: | Custom Designed Color | Open Style: | Sliding And Folding |
| Position: | Commercial | ||
| High Light: | sounproof folding partition,movable sound proof partitions |
||
Product Description
Sliding Aluminium Partition Roller Hotel Soundproof Partition Wall Operable Walls
Technical information:
| Series | BG65 | BG85 | BG100 |
| Panel suspension | Top hung only | Top hung only | Top hung only |
| Panel thickness | 65 mm | 85 mm | 100 mm |
| Max height | 4000 mm | 6000 mm | 18000 mm |
| Panel width | 500-1200 mm | 500-1200 mm | 500-1200 mm |
| Face material | 9 mm | 9 mm | 12 mm |
| Pass doors | Single door or Double door | ||
| Sound insulation | 20-32dB Rw | 28-36dB Rw | 32-50dB Rw |
|
Finish Material |
Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized) | ||
Specification:
The soundproof wall partition is a kind of operable wall that can divide a large space into a small space or a small space into a large space at any time according to needs and has a general wall function. It can serve as a multi-purpose room with multiple functions.
The soundproof partition has the characteristics of easy installation, reliability, industrial production, fire prevention, and environmental protection.
Soundproof partition wall feature:
Hinged pair panels for quick and easy operation.
Robust aluminum frame construction for demanding environments.
Room divider wide range of surface finishes.
Partial and fully operating panels available.
Partition divider just only top hung supported without floor track.
Introduction:
The soundproof partition wall is our individual panel partition system offering an acoustic insulation rating of up to 53 dB.
Ideally suited for high specification applications due to the sheer flexibility, numerous stacking arrangements available and the impressive acoustic qualities this system offers.
The panels are operated by means of an internal scissor-jack mechanism and move effortlessly along an aluminium head track, when closed they form a secure fixed wall.
Movable wall system is a high quality bespoke movable wall system to suit timber panels up to 150 kilograms in weight, there are multiple options for Door types, parking areas and track layouts. Each door is a top hung straight sliding panel which sits inline with the other doors these panels can be moved into a parking area when the wall needs to be opened, pivot panels can be fixed or converted into sliding doors. Timber movable walls can be created to suit any space within reason.
Main material:
Soundproof partition paint-free decorative material has a natural texture, clear wood grain, and can be compared with logs. There are all kinds of wood species popular in the world, and there is no color difference on the surface of the product.
The product design is elaborate, the color matching is reasonable, the construction is convenient, and the saw is good.
Cut, never rupture, repair and trim, use paint-free line matching, glue with glue, no need to worry about ash after nailing, and no need to paint, can save labor and paint fee after construction, avoid paint on the human body Unhealthy odor and carcinogens not only save a long-term maintenance and care costs, but also shorten the construction time, the effect is elegant, the cost is reduced, so it is green, non-toxic, tasteless, pollution-free cross-century new generation of paint-free decoration Materials, products lead the new trend of decorative materials with their benefits.
The movable partition paint-free plate is one of the decorative plates. It has the characteristics of washing, abrasion resistance, moisture resistance, etc. and is economical. It is a good helper for modern decoration partitions.
Our service:
We design and manufacture value for money products with a one year warranty on all the outstanding ranges illustrated in this brochure.
We offer a complete service package covering site surveys, CAD technical drawings, and quotation presentation. Emphasis is placed on quality assurance backed by a comprehensive after sales service.
