Fold-able Banquet Room Operable Soundproof Meeting Room Sliding Partition Walls With Cheap Price
BUNGE Partition Wall Description
Partition Wall are array of Aluminum Framed wall panel.Each Panel is range from 600mm to 1200mm in width and up to 17m in height.All panel is hung through the wheel on wall panel.When moving a wall panel,there is 20-25mm gap between the top of the panel and the underside of the head track,there is a similar gap between the bottom of the of the panel and the floor.Once the paenl is positioned,the panel is locked by top&bottom retractable pressure seal form a solid wall.Movable partition Wall usually is used in the area like multi-purpose Hall,Conference Room,Exhibition Hall,Stadium ,Call Center ,Church,Office,Hotel,Restaurant and so on.
High Partition Walls is designed for partition wall as high as 7 m to17m with max soundproof rate 53 dB. Load bearing of each meter is more than 2000 KGS, pulley bearing more than 1600 KGS, used in large area, such as banquet hall, multi-function hall, exhibition center, gym and conference hall. Ultra-high type partition wall is top hung system, hanging stainless wheel sliding in the track smoothly and stability without vibration, the 17 meters high partition can easily moved even being pushed at waist-high. With build-in oriental device, the panel can make a turn automatically as sliding in the straight rail.,
Strength aluminium frame construction for demanding environments.
Multi or Mono Panel for quick and easy operation.
Wide range of surface finishes.
Pass door incorporated enabling access to adjoining rooms.
Stacks one or both ends.
Top hung and floor with rubber seals achieving excellent barrier effect.
Easy Parking On Movable And Operable Partition System
In their stacked position , the elements form a compact package and can be accommodated in the smallest of spaces depending on the room situation . The low weight of the elements and the associated structural advantages are particularly noticeable here.The four standard stacking or parking track systems offer convenient operability with a minimum of noise from the individual elements as they slide into position on movable and operable partition system .
Pre-sale and After-sale Consultant Service
Professional Suggestion and get correct product
Maintenance contracts- to ensure your valuable asset remains in full work order
A full professional design service
Survey and installation guide and supervise as request
A fully experienced installation team
Using top quality materials and components
|Series||BG 65||BG 85||BG100|
|Panel supension||Top hung only||Top hung only||Top hung only|
|Panel thickness||65 mm||85 mm||100 mm|
|Max height||400 mm||600 mm||800 mm|
|Panel width||600-1230 mm||600-1230 mm||600-1230 mm|
|Face material||9 mm||9 mm||9 mm|
|Pass doors||Single Door or Double Door|
|Sound insulation||20 – 32 db||28 – 36 db||32 – 50 db|
|Finish Material||Plywood / MDF /Laminate / Melamine / Gypsum|
|Board / Fabric / Insulation / Fireproof /Wall Paper /Vinyl /Painting /etc,(Customized)|
