|Produce Name:||Movable Partitions Wall||Finish:||Melamine ,fabric，MDF|
|Thickness:||65 Mm||Application:||Office, Church ，Auditorium，school|
|Advantage:||Soundproof,Sliding ,movable||Service:||OEM ODM|
Hot Sale Modern Office Excellent Quality Banquet Hall Removable Leather Finish Partition Wall
Panel Configuration – The movable partition wall panels are customized to meet specific requirements. Each movable partition walls board thickness is 100mm and max width is 1200mm. Each single movable partition wall panel is welded with a welded aluminum frame and 9mm MDF is mounted on both sides of the outer surface. The internal structure is made of steel mechanism, which combines excellent performance at the top and bottom of the telescopic sound seal. Internal space is filled with less than 64 kg/m3 glass wool.
Overhead track system – specific aluminum alloy rails to meet the necessary stacking requirements. The intersection design should prevent the track wheel from falling into the track groove. Heavy-duty multi-way roller enables easy movement of the sliding movable partition walls for rooms through the ceiling track.
The movable room partition walls has a unique fast seal winding mechanism and a solid vertical seal edge profile to ensure that all panels fit perfectly.
Sound Seal System – Built-in excellent retractable top and bottom seals are anodized by extruded aluminum channels, rubber sealed, and operated by a handle with a cap lock system with spring-loaded telescopic rods. The vertical seal of each panel is made of thick and tongue-type extruded aluminum laminated with rubber seal.
Top and bottom seals do not collected to the ceiling track and floor during panel’s movement. When the sound seals are combined, the movable partition walls panel is placed in a stable position, and the top and bottom seals are compressed on the rails and floors by tight acoustic seals, including adjustable telescopic panels.
Acoustic Rating – Movbale partition walls with high acoustic performance should provide an average sound attenuation of 45Db to 50DB.
Weight – The weight of each movable partition walls panel should be an average of 40 kg/m2, depending on the panel size.
Panel surface – By default it’s 9mm MDF board. However, it can be adapted to any decorative design, such as wood veneer, fabric, etc.
Applications and operations – The movable partition walls consist of a series of single flat wall panels that are manually operated and allow stacking flexibility of the center or remote side.
|Series||BG 65||BG 85||BG100|
|Panel supension||Top hung only||Top hung only||Top hung only|
|Panel thickness||65 mm||85 mm||100 mm|
|Max height||400 mm||600 mm||800 mm|
|Panel width||600-1230 mm||600-1230 mm||600-1230 mm|
|Face material||9 mm||9 mm||9 mm|
|Pass doors||Single Door or Double Door|
|Sound insulation||20 – 32 db||28 – 36 db||32 – 50 db|
|Finish Material||Plywood / MDF /Laminate / Melamine / Gypsum|
|Board / Fabric / Insulation / Fireproof /Wall Paper /Vinyl /Painting /etc,(Customized)|
