Acoustic Movable Operable Partition Wall For Hotel Space Separating
Product Details:
Place of Origin: | China(mainland) |
Brand Name: | EBUNGE |
Model Number: | 65 Series Partitions wall |
Payment & Shipping Terms:
Minimum Order Quantity: | No MOQ |
---|---|
Price: | USD 80-90 Square meters |
Packaging Details: | Partition board paper packaging, and finally packed in wooden carton |
Delivery Time: | 15 days |
Payment Terms: | L/C, D/A, D/P, T/T, Western Union |
Supply Ability: | 5000 Square meters per month |
Detail Information |
|||
Product Name: | 65 Series Partitions Wall | Material: | Fabric Or Leather |
---|---|---|---|
Thickness: | 65 Mm | Advantage: | Movable Soundproof |
Height: | Max 4000 Mm | Usage: | Banquet Hall And Office |
High Light: | movable walls on wheels,movable partitions systems |
Product Description
Soundproof Space Separating Acoustic Movable Operable Partition Wall Price For Hotel
Movable Partition Wall Description
The main advantage of these sound proof wall dividers is the ability to use ceiling rails to support the floor. This is the most common specification because it avoids the need for floor track structures. This is very important for existing buildings where you don’t want floor track to get in the way.
When not in use, the plates are hinged together or stacked at one or both ends. One end panel is usually an access door, which is very useful. The standard soundproof partition can provide up to Rw 45 dB sound reduction.
They are made up of single panels suspended from head rail, and the panels may be stacked at the ends of the partitions or remotely in the appropriate stacking area. Access doors are available. The sound reduction can be enhanced by moving the retractable top and bottom seals.
All the sound proof partitions are customized according to the size required, from the classroom, office to large stadium and conference center.
Sound proof partitions are usually used in schools, offices, hotels, universities, leisure centers, churches, etc., which provide a wide range of possibilities for more efficient use of available space. We will be happy to discuss your detailed requirements and advise on options.
Installation site of partition wall
1: Installation track
Track is the base, is the priority among priorities of all links, through percussion drilling expansion screws, welding Angle iron and other steel materials fixed up.
2: Insert the door panel
The moving door panels are suspended in the rails without any support on the ground.
3: Installation and debugging
Free and flexible, move the door panels according to whatever you need to change the layout
4: Close against the wall
Convenient collection, save space
Technical Details
Series | BG65 | BG85 | BG100 |
Panel suspension | Top hung only | Top hung only | Top hung only |
Panel thickness | 65mm | 85mm | 100mm |
Max height | 4000mm | 6000mm | 18000mm |
Panel width | 500-1200 mm | 500-1200 mm | 500-1200 mm |
Face material | 9mm | 9mm | 12 mm |
Passdoors | Single door or Double door | ||
Sound insulation | 28-38dB Rw | 28-42dB Rw | 32-50dB Rw |
Finish Material | Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc.(Customized) |
