MDF Movable Sound Proof Partitions Telescopic Sleeve Panel For Hotel
Product Details:
| Place of Origin: | Guangzhou, China |
| Brand Name: | BUNGE |
| Certification: | ISO9001 |
| Model Number: | 85 mm sound proof partitions |
Payment & Shipping Terms:
| Minimum Order Quantity: | No MOQ, small quantity welcomed |
|---|---|
| Price: | US $86-108 per square meter |
| Packaging Details: | Paper carton, outside with wooden boxes |
| Delivery Time: | 12-20 days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 20000 square meters per month |
|
Detail Information |
|||
| Product Name: | Sound Proof Partitions | Application: | Hotel Sound Proof Partitions |
|---|---|---|---|
| Finish: | Melamine,fabric Or Leather | Last Panel Closure: | Telescopic Sleeve Panel |
| Style: | Sound Proof | Color: | Optional |
| High Light: | sounproof folding partition,movable sound proof partitions |
||
Product Description
MDF Movable Partitions Operable Soundproof Partition Walls Panels For Hotel
Sound proof partitions details
BUNGE hotel sound proof partitions are able to supply you with acoustic partitions that will look good and last for years to come, with endless possibilities of surface finishes, from standard laminate, real wood veneers, painted finishes, black board, or ready to onsite decorate by customer i.e. painting / wallpapering etc. Hotel sound proof partitions are top hung so have no floor tracks, and are more forgiving on uneven floors, with sound reduction available up to 52db.
Options include full height or inset pass doors, and glazing panels, easy to operate each panel,is manually positioned and secured into place with a winding handle to operate the mechanical seals top and bottom.
All of our hotel sound proof partitions are of the highest quality, very robust and easy to manoeuvre, and manufactured in the China, the hotel sound proof partitions panels can be stacked either in-line (single point suspension) or off-line at either end of the top track (two point suspension), with different track variations possible to suit your needs.
Hotel sound proof partitions allow you to segregate your space for maximum potential, and are the perfect flexible space-saving solution for areas that require a sound proof partition with a higher specification.
Technical data of sound proof partition walls:
| Model | BG65 Series | BG80 Series | BG100 Series | BG High-Series | |
| Suspensionsystem | Aluminum hanging | Steal Hanging | |||
| Basic Thickness | 65 mm | 80 mm | 100 mm | 100 mm | |
| Total thickness | 65/75/85/95mm | 80/90/100/110mm | 100/120/130mm | 100/120/130mm | |
| Max Height | Up to 3800 mm | Up to 6000 mm | Up to 8000 mm | Up to 15000 mm | |
| Width | 600-1230mm | 600-1230mm | 800-1230mm | 800-1230mm | |
| Floor/Ceiling Sealing Strength | Telescopic aluminum tube with rubber strip. | ||||
| Side walls sealing strength | Double seal tape. | ||||
| Sound insulation level | 26-30 db | 28-34 db | 32-40 db | 42-52 db | |
| Panel structure | Aluminum frame with wooden keel | Aluminum frame with steel keel | |||
| Surface material | Melamine laminate/fabric/PU leather/wallpaper/veneer/customized | ||||
Hotel sound proof partitions installation
1. After the hotel sound proof partitions rail is transported to the construction site, the construction personnel should first understand the general decoration style of the site, including the ceiling shape, the ground shape, whether there is a skirt line on the wall, etc., timely communicate with the on-site woodworker, and then release the line to determine the track installation. position;
2. After the horizontal line is placed, the construction side will determine the layout direction of the air-conditioning duct fire-fighting pipe, and it is convenient to determine the steel structure installation form, whether it is a straight pull or a diagonal support or a U-slot fix. These are responsible installation teams. Do the preparation before the construction, otherwise work and do things, when the impact on the site construction layout, but also to rework, seriously affect the construction progress, will also bring unnecessary trouble to Party A;
3. After the hotel sound proof partitions track is installed, the track level will be self-checked again, and finally the steel structure will be rust-proofed, and then Party A will be notified and the position of the track movable port will be clearly stated. When the ceiling is clearly indicated, it cannot be fixed with the track. Otherwise,the hotel sound proof partitions panel will likely damage the integrity of the ceiling.
