Product Details:

Place of Origin: Guangzhou, China
Brand Name: BUNGE
Certification: ISO9001
Model Number: 65 mm foldable partition walls

Payment & Shipping Terms:

Minimum Order Quantity: No MOQ, small quantity welcomed
Price: US $86-108 per square meter
Packaging Details: Paper carton, outside with wooden boxes
Delivery Time: 12-20 days
Payment Terms: T/T, Western Union
Supply Ability: 20000 square meters per month
Get Best Price Contact Now

Detail Information

Product Name: Foldable Partition Walls Frame Material: Anodized Aluminum 6063-T5
Track Material: Anodized Aluminum 6063-T5 Surface: Melamine
Partition Weight: 25 Kg/m2 Base Board: 9 Mm MDF Board
High Light:

acoustic folding partition

,

folding room partitions

Product Description

Top Hanging System Acoustic Operable Wall Foldable Door Partition Walls



Foldable partition walls details



BUNGE foldable partition walls are used to divide meeting rooms, conference rooms, restaurant and banquet halls etc., it provides convenient and effective space management solutions, the panels move on a ceiling track with no requirement of floor guides or rails, its has been extensively applied to hotel industry.


BUNGE offers products and service with the end user in mind. We build in features that provide benefits to the owner over the life of the partition. Features such as protective edge trim will keep your partitions looking good for many years to come.


The foldable partition walls consist of a series of interlocking flat panels and the fast set retractable top and bottom seals provide the easiest in-field operation, a simple half-turn of the waist high removable handle extends or retracts the sound seals.


The quick set retractable seals save the owner a great deal of time during setup and take down

Time means money, especially for clients that rent their facilities for meetings and other functions.



BUNGE provides panel finishes such as melamine, fabric, leather, wood veneer, high-pressure laminate or other custom surfaces, foldable partition walls panels also be supplied unfinished(raw mdf or plywood) for field decoration to compliment the building environment.

Top Hanging System Acoustic Foldable Partition Wall Anodized Aluminum 6063-T5 Frame 0

Technical data of  foldable partition walls:



Model Weight
(kg/m)
Fire Rating(min) STC Performance Specification Carrier
Thickness
(mm)
Width(mm) Height(mm) Top Seal(mm)/ Pressure(kg) Bottom Seal(mm)/ Pressure(kg) LCP stretch (mm)
BG65-32 22 60 32db 65 680-1212 2000-4500 22.5/35 22.5/35 140 60#
65#
80#
BG65-38 27 60 38db 65 680-1212 2000-4500 22.5/35 22.5/35 140
BG65-45 35 60 45db 65 680-1212 2000-4500 22.5/35 22.5/35 140



Technical data of Type 85 foldable partition walls :

Model Weight
(kg/m)
Fire Rating(min) STC Performance Specification Carrier
Thickness
(mm)
Width(mm) Height(mm) Top Seal(mm)/ Pressure(kg) Bottom Seal(mm)/ Pressure(kg) LCP stretch (mm)
BG80-40 30 60 40db 85 680-1212 2000-5500 22.5/35 22.5/35 140 60#
80# 100#
BG80-45 38 60 45db 85 680-1212 2000-5500 22.5/35 22.5/35 140
BG80-48 47 60 48db 85 680-1212 2000-5500 22.5/35 22.5/35 140



Technical data of Type 100 fodlable partition walls :

Model Weight
(kg/m)
Fire Rating(min) STC Performance Specification Carrier
Thickness
(mm)
Width(mm) Height(mm) Top Seal(mm)/ Pressure(kg) Bottom Seal(mm)/ Pressure(kg) LCP stretch (mm)
BG100-43 38 60 43db 100 680-1219 2000-7500 30/40 30/40 140 60#
80# 100#
BG100-48 46 60 48db 100 680-1219 2000-7500 30/40 30/40 140
BG100-53 55 60 53db 100 680-1219 2000-7500 30/40 30/40 140

Top Hanging System Acoustic Foldable Partition Wall Anodized Aluminum 6063-T5 Frame 1



Notes:



1. The choice of the foldable partition walls model: according to the wind that decorated to design the suitable fodlable partition walls modeling, such as classical Chinese style options screen partition model, european-style multi-select fashionable glass partition and metal partition. The effect of different styles of partition foil is also different.

2. The choice of foldabble partition walls color, on the choice of partition color according to the whole color of the hotel lobby to select suitable partition color to match. avoid alternative and not suitable feeling.

Top Hanging System Acoustic Foldable Partition Wall Anodized Aluminum 6063-T5 Frame 2
