Dinning Hall Movable Panel Sound Proof Partition Wall Max 4 Meter Height
Product Details:
| Place of Origin: | China (mainland) |
| Brand Name: | EBUNGE |
| Model Number: | 65 mm movable partition wall |
Payment & Shipping Terms:
| Minimum Order Quantity: | NO MOQ |
|---|---|
| Price: | US$82-118 per square meter |
| Packaging Details: | Carton package, MDF batten on four section sides, foam board on both front face. |
| Delivery Time: | 10-20 days |
| Payment Terms: | T/T, L/C, D/A, D/P |
| Supply Ability: | 5000 Square meter per month |
|
Detail Information |
|||
| Product Name: | Movable Partition Wall | Material: | MDF |
|---|---|---|---|
| Color: | Customized | Size: | Customized |
| Thickness: | 65mm | Application: | Office,Restaurant,etc. |
| Height: | Max 4 Meter | Width: | 500-1220mm |
| Feature: | Space Saving,Water-proof&air-proof&sound Isolation&heat Isolation | Advantage: | Free Of Floor Track |
| Service: | OEM/ODM | ||
| High Light: | movable sound proof partitions,movable soundproof partition |
||
Product Description
Soundproof Hotel Dinning Hall Movable Panel Operable Wall Partition
Product Description
Now people are getting more and more detailed about the division of space. Different areas of the house have different functions. At this time, it is necessary to separate and divide different spaces. The traditional way of dividing is to use partition walls. Now many families are flexible in space. The requirements are higher, so the moving partition wall came into being.
| Series | BG65 | BG85 | BG100 |
| Panel suspension | Top hung only | ||
| Panel thickness | 65mm | 85mm | 100mm |
| Max height | 4000mm | 6000mm | 8000mm |
| Panel width | 600-1230mm | ||
| Face material | 9mm | 9mm | 12mm |
| Sound insulation | 20-32db RW | 30-38db RW | 35-45db RW |
| Weight | 20-30 kg/sq M | 22-35kg/sq M | 28-40kg/sq M |
| Track system | Single or two point | ||
| Frame construction | Aluminum frame | ||
| Finish materials | Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized) | ||
Advantages
1. No rail suspension: the floor has no track, just install the track on the ceiling;
2. Stable and safe: stable and reliable after partitioning, not easy to swing;
3. Compartment environmental protection: the effect of the compartment is good, the maximum sound insulation coefficient can reach 50db;
4. Insulation and energy saving: excellent thermal insulation performance, according to different occupancy rates, the hall is divided into small spaces to reduce air conditioning power consumption;
5. Efficient fire prevention: It is made of high-efficiency fireproof material and has good fireproof performance;
6. Beautiful and generous: the surface is arbitrarily decorated, and can be combined with the interior decoration effect;
7. Retractable and flexibl : When closing the board, the partition can be hidden in the special storage cabinet, which does not affect the overall appearance;
9. Wide range of applications: products used in hotels, hotels, restaurants, conference halls, exhibition halls, high clean factories and offices.
About the type of movable partition wall
We have 4 types of movable wall , 65type , 85type , 100type and 125 ultra-high type . You can choose the right folding wall upon the Height and Soundproof requirement as following,
65 type— Max height 4m, soundproof: 20dB to 32dB
85 type— Max height:5.5m,Soundproof:30dB to 38dB
100 type— Max height:7m,Soundproof: 35dB to 45dB
125ultra-height — Max height:15m,Soundproof : 35dB to 45dB
How to choose the decorative surface of the folding partition wall
1. The base plate of the mobile partition wall is made of MDF, plywood, or gypsum board. You can process the decorative surface on the spot, such as wallpaper, veneer and paint.
2. Finishing can also be done by our company, such as melamine board (economical), hard fabric or PU leather (fashion type), soft fabric or PU leather (high sound insulation type), and other cover frame finishing(high-grade type).
What are the conditions for the renovation site?
Because the Bunge partition series products are groundless, suspended movable partitions, the rails need to be installed under the slab concrete to ensure sufficient force. The minimum distance of the false ceiling slab must be 180mm.
