Banquet Removable Movable Partition Walls With Manual Operating System
Product Details:
Place of Origin: | China (mainland) |
Brand Name: | BUNGE |
Model Number: | 85mm movable partition wall |
Payment & Shipping Terms:
Minimum Order Quantity: | NO MOQ |
---|---|
Price: | US$82-118 per square meter |
Packaging Details: | Carton package, MDF batten on four section sides, foam board on both front face. |
Delivery Time: | 10-20 days |
Payment Terms: | T/T, L/C, D/A, D/P |
Supply Ability: | 5000 Square meter per month |
Detail Information |
|||
General Use: | Soundproof Partition Walls Are Used For Interior Decoration | Material: | MDF |
---|---|---|---|
Color: | Customized | Thickness: | 85mm |
Height: | Max 6 Meter | Width: | 500-1228mm |
Feature: | Space Saving,soundproof | Advantage: | Free Of Floor Track |
Finishing Option: | Melamine | Service: | OEM/ODM |
High Light: | acoustic sliding partition,sliding folding partition |
Product Description
Banquet Removable Movable Wall Partition System With Manual Operating System
Product Description
Bunge movable partitions are a series of individually operated panels along a track system designed for maximum space planning flexibility. They can be arranged quickly, easily and efficiently.
The Bunge Partition Walls is a nice quality movable wall system that allows you to optimize the use of available space with speed and ease.
Series | BG65 | BG85 | BG100 |
Panel suspension | Top hung only | ||
Panel thickness | 65mm | 85mm | 100mm |
Max height | 4000mm | 6000mm | 8000mm |
Panel width | 600-1230mm | ||
Face material | 9mm | 9mm | 12mm |
Sound insulation | 20-32db RW | 30-38db RW | 35-45db RW |
Weight | 20-30 kg/sq M | 22-35kg/sq M | 28-40kg/sq M |
Track system | Single or two point | ||
Frame construction | Aluminum frame | ||
Finish materials | Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized) |
Bunge Soundproof Movable partition Features:
1- 65mm ,85mm, 100mm aluminum frame thickness panel ,Max height up to 15 meters.
2-Top supported without floor track or guide, only have track on the ceiling.
3- clear anodized extruded aluminum tracks and frames,customized powder coated color are available.
4- Sound insulation certificate :STC 32db to 45db
5- Available in wide range of finishes, melamine ,fabric/PU leather, HPL, printing etc.
6- Fast delivery and Rich experiences in oversea project installation guide & supervision.
What is finishing face?
The bottom panel is MDF or plywood, which is unfinished face. You can do decoration on site, such
as wallpaper, paint, etc.
We can also provide the product with finished face, such as faux wood, Woven fabric and Leather.
About product warranty
We provide three years warranty for movable partition wall and 10 years warranty for accessories
About the soundproof quality
From 30 dB to 45 dB, depends of which type and what partition surface finished you need. Contact
us and we will provide professional suggestions.
How do the movable partition wall work?
The continuously hinged panels are pulled from their parked position to 'close' (or extend) the wall and
pushed back to the parked position to 'open' (or fold)the wall. Final flat alignment of wall panels is assisted
pneumatically by a gas piston located in the top track. A lever or recess handle is fitted to the lead panel
and this combined with a vertical rebated profile provides the system with its pass door. The door is available
with or without a lock cylinder.
How do the goods packing?
corrugating paper packaging, MDF batten cover all around corner.
The movable wall panel and track, fittings will be packed separately.
What is Procurement procedure?
Firstly, send us the shop drawings(if the shop drawings is not available, you can tell us the height from false
ceiling to finished floor and width from wall to wall)
Secondly, we offer you the movable wall layout drawings for your confirmation
Thirdly, we quote the movable wall in accordance with confirmed drawings.
