Decorative Panel Movable Partition Walls Max 4000 mm Height Customized Color
Product Details:
| Place of Origin: | Guangdong ,China |
| Brand Name: | BUNGE |
| Model Number: | 65 Series Partitions wall |
Payment & Shipping Terms:
| Minimum Order Quantity: | No MOQ |
|---|---|
| Price: | USD 80-90 Square meters |
| Packaging Details: | Partition board paper packaging, and finally packed in wooden carton |
| Delivery Time: | 15 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union |
| Supply Ability: | 5000 Square meters per month |
|
Detail Information |
|||
| Product Name: | Acoustic Partition Walls | Thickness: | 65 Mm |
|---|---|---|---|
| Height: | Max 4000 Mm | Width: | 750~~1200mm |
| Type: | 65 Type | Material: | Aluminium |
| Color: | Customized | Service: | OEM/ODM |
| Frame Material: | Aluminium | Application: | Office,Restaurant |
| High Light: | movable partitions systems,acoustic movable walls |
||
Product Description
Decorative Panel Partitions Cheap Folding Sliding Movable Partition Wall For Hotel
| Series | BG 65 | BG 85 | BG100 |
| Panel supension | Top hung only | Top hung only | Top hung only |
| Panel thickness | 65 mm | 85 mm | 100 mm |
| Max height | 400 mm | 600 mm | 800 mm |
| Panel width | 600-1230 mm | 600-1230 mm | 600-1230 mm |
| Face material | 9 mm | 9 mm | 9 mm |
| Pass doors | Single Door or Double Door | ||
| Sound insulation | 20 – 32 db | 28 – 36 db | 32 – 50 db |
| Finish Material | Plywood / MDF /Laminate / Melamine / Gypsum | ||
| Board / Fabric / Insulation / Fireproof /Wall Paper /Vinyl /Painting /etc,(Customized) | |||
Product description
As the ultra high version, type 125 movable partition wall systems are made up of a series of individual partition panel with ceiling track which make it be able to slide along the track. These movable partition walls on wheels are widely used in hotels, shops, exhibition centers, exhibition center, colleges, clubs, art centers, stadium, sports centers, offices, testing center, bowling centers, schools, conference center, golf clubs, etc.
Structure of Pattern 125 Movable Sound Proof Partition Wall
The nominal thickness of movable partition wall is 100mm.
The movable partition wall panel frames are made of standard construction grade aluminum alloy.
Surface panels are available in 12mm thick MDF board, particle board, gypsum board.
Specification
Thickness: 100mm
Width: 700-1200mm
Height: Max15000mm
Suspension: Top hang with single or double carrier
Acoustic performance: up to STC 45dB
Movable Partition Wall Suspension Systems
The aluminum track system is made of natural construction grade aluminum alloy.
Each single suspension hanging wall divider panel has vertical metal bearing wheels on the track.
Different options for track crossings can be used to meet specific design requirements.
Single or dual panel suspension options to accommodate different parking layout designs and requirements.
Panel Finishes
The moving partition walls finish panels are available in wallpaper, PVC laminates, fabric, melamine finishes and so on.
Note: Pattern 125 movable partition walls cost is higher than other patterns, if your project is not very high. You may choose pattern 100 soundproof partition wall.
