Conference Rooom Sliding Partition Walls Sound Proof Materials No Need Floor Track

China Conference Rooom Sliding Partition Walls Sound Proof Materials No Need Floor Track supplier
Conference Rooom Sliding Partition Walls Sound Proof Materials No Need Floor Track supplier Conference Rooom Sliding Partition Walls Sound Proof Materials No Need Floor Track supplier Conference Rooom Sliding Partition Walls Sound Proof Materials No Need Floor Track supplier Conference Rooom Sliding Partition Walls Sound Proof Materials No Need Floor Track supplier

Large Image :  Conference Rooom Sliding Partition Walls Sound Proof Materials No Need Floor Track

Product Details:

Place of Origin: China,Guangzhou
Brand Name: BUNGE
Certification: ISO9001
Model Number: Series 65 mm sliding partition wall

Payment & Shipping Terms:

Minimum Order Quantity: 10 square meters
Price: 86 /124 dollar per square meter
Packaging Details: Carton package, MDF batten on four section sides ,foam board on both front face.
Delivery Time: Shipped in 10 days after payment, based on the quantity.
Payment Terms: D/A, D/P, L/C, T/T, Western Union, MoneyGram
Supply Ability: 5000 square meters per month
Contact Now
Detailed Product Description
Application: Conference Room,office Height: Less Than 4 M
Material: Aluminium Frame And Plywood Thickness: 65 Mm
Service: OEM Service Open Style: Sliding
Product Name: Sliding Partition Wall Surface: Plywood,Mdf Bare Finish,melamine

No Need Floor Track Conference Rooom Sound Proof Sliding Wall Partition Materials



Description:



The sliding wall partition is a kind of operable wall that can divide a large space into a small space or a small space into a large space at any time according to needs and has a general wall function. It can serve as a multi-purpose room with multiple functions.



The sliding partition has the characteristics of easy installation, reliability, industrial production, fire prevention, and environmental protection.



Technical information:



Series BG65 BG85 BG100
Panel suspension Top hung only Top hung only Top hung only
Panel thickness 65 mm 85 mm 100 mm
Max height 4000 mm 6000 mm 18000 mm
Panel width 500-1200 mm 500-1200 mm 500-1200 mm
Face material 9 mm 9 mm 12 mm
Pass doors Single door or Double door
Sound insulation 20-32dB Rw 28-36dB Rw 32-50dB Rw



Finish Material

Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized)



Conference Rooom Sliding Partition Walls Sound Proof Materials No Need Floor Track



Application:



At present, movable partition and fixed partition series products are widely used in hotels, hotels, multi-purpose halls, conference rooms, banquet halls, office buildings, exhibition halls, financial institutions, government offices, hospitals, factories and other occasions.



Feature:



1.it is very convenient to be able to expand or reduce it according to different needs.



2.Preservation and storage are appropriate and convenient.



3.The sound insulation is good, not only the sound insulation, but also the heat insulation.



4.The usual mobile partition, its design is relatively fashionable. So, be able to put it anywhere. Can also play a certain beautification role.



5.The stability of the mobile partition is strong. It is not easy to offset the position.



Conference Rooom Sliding Partition Walls Sound Proof Materials No Need Floor Track



Installing details:



1. Remember that the track should be loose enough above all the brackets to ensure that the track is paused;



2. After the track of the movable partition is laid, tighten the connection of all the tracks and adjust the horizontal level of the track correctly. The direction of the track installation must also be horizontal and straight;



3. When the track facility is installed, the sound insulation and mineral wool are the necessary plates for installation;



4. Before closing the movable partition, the height of the carrier must be adjusted, and the straight angle of the track should be checked to make the track partition work well;



5. Check all active partitions, whether they are all vertical, if there is no damage, you can enter the edge of the aluminum frame of the rubber seal vertically and not bend;



If the orbital direction is horizontal, but the active partition is suspended, then the carrier height must be adjusted.
