Melamine Surface Folding Panel Partition / Operable Partition Walls
Product Details:
Place of Origin: | China,Guangzhou |
Brand Name: | BUNGE |
Certification: | ISO9001 |
Model Number: | Series 65 mm folding partition walls |
Payment & Shipping Terms:
Minimum Order Quantity: | 10 square meters |
---|---|
Price: | 82 / 138 dollar per square meter |
Packaging Details: | Carton package, MDF batten on four section sides ,foam board on both front face. |
Delivery Time: | Shipped in 10 days after payment, based on the quantity. |
Payment Terms: | D/A, D/P, L/C, T/T, Western Union, MoneyGram |
Supply Ability: | 5000 square meters per month |
Detail Information |
|||
Height: | Less Than 4 M | Thickness: | 65 Mm |
---|---|---|---|
Surface: | Melamine,fabric,leather | Application: | Banquet Hall,conferene Room |
Service: | OEM Service | Material: | Mdf Board |
Product Name: | Folding Wall Partition | Color: | Multi Color |
High Light: | soundproof folding partition,folding room partitions |
Product Description
Soundproof Folding Wall Panel Operable Partitions Cost for Banquet Hall
Specification:
The moving partition wall is also called soundproof partition, removable partition, and track partition. The mobile partition has the characteristics of easy installation, reliability, industrial production, fire prevention and environmental protection.
Movable partitions bring great convenience to people's work. For example, the active screen, you can fold it aside when you need it, so that the two spaces are temporarily joined together to make it bigger and convenient for temporary departmental meetings. These products use a ceiling track system that is as strong as a wall.
Feature:
1.it is very convenient to be able to expand or reduce it according to different needs.
2.Preservation and storage are appropriate and convenient.
3.The sound insulation is good, not only the sound insulation, but also the heat insulation.
4.The usual mobile partition, its design is relatively fashionable. So, be able to put it anywhere.
Can also play a certain beautification role.
5.The stability of the mobile partition is strong. It is not easy to offset the position.
Advantage:
1.Sound proof board is modernized decoration style. It can separate the space speedy and conveniently. And it has sound insulation and heat insulation and fireproof function.
2.The room dividers is made from high density s/s frame, special made rubber, excellent sound insulation cotton and finish board etc. the finish board is flat and hard.
3.The finish board is inserted in the aluminum track, assembled with muti direction wheels; the board can be stored in may different ways.
4.It doesn't need track on the floor,we only hang the track on the ceilings and it can be at the same plane with the ceiling decoration. It won't affect the whole decoration style.
5.Around the board ,there is sound insulation rubber, it can help to insulate the sound entering.
6.The operation ways is much easier, it's better than the old ways which was use spring before.
Technical information:
Series | BG65 | BG85 | BG100 |
Panel suspension | Top hung only | Top hung only | Top hung only |
Track system | Single or twin point | Single or twin point | Single or twin point |
Panel thickness | 65mm | 80mm / 85mm | 100mm |
Panel height | Up to 4000mm | Up to 6000mm | Up to 18000mm |
Max height | 4000mm | 6000mm | 18000mm |
Panel width | 600-1230mm | 600-1230mm | 600-1230mm |
Frame construction | Aluminum frame | Aluminum frame | Aluminum frame |
Face material | 9mm | 9mm / 12mm | 12mm |
Fire safety | Optional Class I or O | Optional Class I or O | Optional Class I or O |
Vertical profiles | Aluminum anodised with sealing profiles | Aluminum anodised with sealing profiles | Aluminum anodised with sealing profiles |
Retractable seals | Aluminum black with double rubber seals |
Aluminum black with double rubber seals | Aluminum black with double rubber seals |
Operation of seals | Manual, with supplied operating handle |
Manual, with supplied operating handle | Manual, with supplied operating handle |
Locking | Optional lock to pass doors | Optional lock to pass doors | Optional lock to pass doors |
Pass doors | Single open in panel or double open in two panel |
Single open in panel or double open in two panel | Single open in panel or double open in two panel |
Sound insulation | 20-32dB Rw | 28-36dB Rw | 32-50dB Rw |
Weight | Approx 22-35kg/sq M | Approx 25-40kg/sq M | Approx30-48kg/sq M |
Finish Material | Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized) |
Our service:
We design and manufacture value for many products with one year's warranty on all the outstanding ranges illustrated in this brochure.
They offer a complete service package covering site surveys, CAD technical drawings, and quotation presentation. Emphasis is placed on quality assurance backed by a comprehensive after sales service.
