Wooden Removable Folding Partition Walls 65mm Thickness Melamine Surface
Product Details:
Place of Origin: | China (mainland) |
Brand Name: | BUNGE |
Model Number: | 65 mm folding partition wall |
Payment & Shipping Terms:
Minimum Order Quantity: | NO MOQ |
---|---|
Price: | US$82-118 per square meter |
Packaging Details: | Carton package, MDF batten on four section sides, foam board on both front face. |
Delivery Time: | 10-20 days |
Payment Terms: | T/T, L/C, D/A, D/P |
Supply Ability: | 5000 |
Detail Information |
|||
Color: | Customized | Material: | MDF |
---|---|---|---|
Surface: | Melamine | Thickness: | 65MM |
Height: | Max 4 M | Width: | 600-1230 MM |
High Light: | acoustic folding partition,folding room partitions |
Product Description
65 mm thickness melamine surface wooden removable folding soundproof partition wall
Product Description
Bunge 65mm folding partition wall divide your space flexibly with high sound insulation performance.no need floor track, top hung sys.
Series | BG65 | BG85 | BG100 |
Panel suspension | Top hung only | ||
Panel thickness | 65mm | 85mm | 100mm |
Max height | 4000mm | 6000mm | 8000mm |
Panel width | 600-1230mm | ||
Face material | 9mm | 9mm | 12mm |
Sound insulation | 20-32db RW | 30-38db RW | 35-45db RW |
Weight | 20-30 kg/sq M | 22-35kg/sq M | 28-40kg/sq M |
Track system | Single or two point | ||
Frame construction | Aluminum frame | ||
Finish materials | Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized) |
Technical Description Feature
1.Change the room space freely.
2.Heavy Track loading capacity make sure the safety of Partition.
3.Precise welding between separate rail can eliminate repairing and maintenance rate.
4. Partition retract and push easily for one people to handle the operating work.
5.Wide application: can be used in Office place, commercial place, exhibition place, Hospital place.
Advantages:
1. Bunge carrier Dupont POM materials to meet its best wearing resistant, the high carbon chromium bearing steel has reach to a strength 10.9 grade.
2. Bunge patent, vertical crank handle shaft, made by 304 stainless steel ,thick materials.
3. Bunge double corrosion-resistant aluminum track systems are easy to install and easier to maintain. Extruding enable each section to have a uniform for superior end-to-end alignment. Each capacity-certified track is of extrude architectural grade clear anodized 6063-T6 aluminum.
4. Bunge’s patent, 304 stainless steel LCP panel crank handle shaft cup and operable handle.
5. The safety and stability of movable partition are effected by what kind of keel materials used inside in structure. Bunge fixing the 6063-T5 aluminum keels and keeps every two keels at a distance max no more than 600mm, it can be guarantee the panel stable after many years using. It also can be environmental protection and fire retardant, most of partition manufacturer in domestic which still use wood keel.
Operation:Partitions shall be top supported, manually operated panels stacked in an area nominated in the plans. When closed, the operable wall shall provide a complete sound retardant barrier. No floor track shall be used.
Track: The tracks are made from extruded 6063 – T6 anodized aluminum. The track housing shall utilize grooves and interlocking steel pins for positive alignment of adjacent track sections, and shall be reinforced overhead by drop rod brackets. Aluminum track housing shall include an integral nut slot to accept a hardened square nut for attaching each drop rod bracket to the top of the track.
Trolley: BUNGE Centre/ Side /Remote stacking system with a Two wheeled nylon trolley made with the base Material of POM 45 tempered steel shall be used as per approved stacking method.
We Offer:
1.No floor track and soundproof partition wall
2.OEM and ODM services accepted
3.Free sample provided
4.Using top quality materials and components
5.A fully experienced work team
6.Maintenance contracts to ensure your valuable asset remains in full work order.
