Foldable Removable Soundproof Partition Wall 65mm Thickness PU Leather Surface
Product Details:
| Place of Origin: | China (mainland) |
| Brand Name: | BUNGE |
| Model Number: | 65 mm folding partition wall |
Payment & Shipping Terms:
| Minimum Order Quantity: | NO MOQ |
|---|---|
| Price: | US$82-118 per square meter |
| Packaging Details: | Carton package, MDF batten on four section sides, foam board on both front face. |
| Delivery Time: | 10-20 days |
| Payment Terms: | T/T, L/C, D/A, D/P |
| Supply Ability: | 5000 |
|
Detail Information |
|||
| Color: | Customized | Material: | MDF |
|---|---|---|---|
| Surface: | PU Leather | Thickness: | 85 MM |
| Height: | Max 6 M | Width: | 600-1230 MM |
| High Light: | soundproof folding partition,folding room partitions |
||
Product Description
65 mm thickness PU leather surface folding removable soundproof partition wall
Product Description
Bunge folding partition wall divide your space flexibly with high sound insulation performance.no need floor track, top hung sys.
| Series | BG65 | BG85 | BG100 |
| Panel suspension | Top hung only | ||
| Panel thickness | 65mm | 85mm | 100mm |
| Max height | 4000mm | 6000mm | 8000mm |
| Panel width | 600-1230mm | ||
| Face material | 9mm | 9mm | 12mm |
| Sound insulation | 20-32db RW | 30-38db RW | 35-45db RW |
| Weight | 20-30 kg/sq M | 22-35kg/sq M | 28-40kg/sq M |
| Track system | Single or two point | ||
| Frame construction | Aluminum frame | ||
| Finish materials | Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized) | ||
Technical Description Feature
1.Change the room space freely.
2.Heavy Track loading capacity make sure the safety of Partition.
3.Precise welding between separate rail can eliminate repairing and maintenance rate.
4. Partition retract and push easily for one people to handle the operating work.
5.Wide application: can be used in Office place, commercial place, exhibition place, Hospital place.
Finsh Options
Bunge folding partition wall divide your space flexibly with high sound insulation performance.no need floor track,top hung system. Its magnetic strips are set on the adjacent panels edges ,they will attracted by each other automaticly when they are close enough,have good seal and acoustic performance,each panel limit weight is 450KG,top and bottom telescopic range are 22.5MM. And
65-D32(STC 32),base surface is armor plate, RW=32dB
85-D38(STC 38),base surface is MDF board or plywood,RW=38dB
100-D50 (STC 50), base surface is Melamine board RW=50dB
Interior decorative partition Information:
Bunge movable partition board thickness is 65mm, it can be double or single piece, and can be designed U shape or Lshape door. every panel can board 225kgs weight. The top and bottom flex range is 22.5mm.
Interior decorative partition Character:
A> Galvanized sheet base board: sound insulation coefficient RW=36dB, the density is 30kg/m2;
B>MDF or ply wood base board: sound insulation coefficient RW=32dB, the density is 24kg/m2;
C>Magnesium board base board: sound insulation coefficient RW=26dB, the density is 25kg/m2;
Interior decorative partition Usage:
it is widely used at 2m~3.5m height
We Offer:
◆ A full professional design service
◆ Survey and installation guide
◆ Using top quality materials and components
◆ A fully experienced work team
◆ Maintenance contracts to ensure your valuable asset remains in full work order.
