Accordion Sliding Partition Walls , Decorative Folding Screen Room Divider
Product Details:
Place of Origin: | Guangzhou,China |
Brand Name: | BUNGE |
Certification: | ASTM E90 |
Model Number: | 65 mm sliding partition walls |
Payment & Shipping Terms:
Minimum Order Quantity: | No MOQ, small quantity available |
---|---|
Price: | US $75-108 per square meter. |
Packaging Details: | Paper Carton, outside with wooden boxes. |
Delivery Time: | 15-25 days |
Payment Terms: | T/T, Western Union |
Supply Ability: | 8000 square meters per month. |
Detail Information |
|||
Product Name: | Sliding Partition Walls | Partition Weight: | 25-80 KG/square Meter |
---|---|---|---|
Material: | Aluminum Alloy+MDF | Sample: | Free |
Frame Material: | 6063-T6 Aluminum Alloy | Contract Range: | 22.5 Mm |
High Light: | acoustic sliding partition,sound proof sliding partitions |
Product Description
Cheap and Decorative Folding Screen Room Dividers / Accordion Sliding Partition Walls
1.Top hung system without floor track, Sound insulation coefficient :STC 26 to 55db based on the material choose.
2.Thickness panel:65mm,85mm,100mm,125 ultra-high system, height from 2meters to 18meters.
3.Extensive choice for surface finishes are available.such as Wood Veneer,Melamine.Leather,Fabric,Glass,Tile……
Series | Thickness (mm) | Applied height (mm) | Width of panel (mm) | Acoustical reduction coefficient (db) | Hanging weight | Retractable Range of Top/bottom(mm |
65 | 65 | 2000~4500 | 600~1228 | 26~36 | 22~30kg/m2 | 22.5 |
85 | 85 | 2000~6000 | 600~1228 | 35~50 | 30~40kg/m2 | 22.5 |
100 | 100 | 2000~10000 | 600~1228 | 43~53 | 36~45kg/m2 | 30 |
110 | 110 | 2000~180000 | 600~1228 | 45~53 | 38~50kg/m2 | 30 |
125 | 125 | 2000~180000 | 600~1228 | 50~55 | 70kg/m2 |
30 |
Sliding partition walls materials
Material/hardware details:
Frame and Tracks | 6063-T6 Anodized aluminum alloy |
MDF Board | 760KG/M3 (Executive standard:GB/T11718-2005) |
Rock wool | 80KG/M3 (ASTM Standard) |
Plastic seal |
PVC, tensile strength 8.15MPA (Executive standard:GB/T529-92 GB/T3515-2002) |
Retractable mechanism | Standard 45#steel and spring steel |
Ø The Main Spare Parts produced by Our Own to Insure all quality and system using are smoothly;
|
Sliding partition walls FAQ
Q5:Can you assist for installation?
Yes, we can arrange to assist in installation if needed.
Sliding partition walls technical information
Model | 65 Sliding Partition Wall |
85 Sliding Partition Wall |
100 Sliding Partition Wall |
Ultrahigh Sliding Partition Wall |
Panel Thickness | 65 MM | 85 MM | 100mm | 100mm |
Panel Width | 680mm-1210mm | 680mm-1230mm | 680mm-1230mm | 680mm-1230mm |
Panel Height | 2000mm-4500mm | 3000mm-6500mm | 5000mm-8500mm | 7000mm-17000mm |
Frame | 6063 T6 Aluminium | 6063 T6 Aluminium | 6063 T6 Aluminium | 6063 T6 Aluminium |
Acoustic alreduction coefficient(db) |
32db | 45db | 60db | 60db |
Hermetic flex distance(mm) |
45mm | 45mm | 45mm | 60mm |
Weight(kg/m) | 17,19,20,24 | 24,25,28,38 | 40,45,48,55 | 60,60,60,60 |
Faceplate Material |
Class-fibr board, Melamine decorative lamminate board, Gypsum board,Color steel plate,Fiberboard, Tempered glass |
Class-fibr board, Melamine decorative lamminate board, Gypsum board,Color steel plate,Fiberboard, Tempered glass |
Class-fibr board, Melamine decorative lamminate board ,Gypsum board, Color steel plate, Fiberboard, Tempered glass |
Class-fibr board, Melamine decorative lamminate board, Gypsum board,Color steel plate,Fiberboard, Tempered glass |
Panel Surface Finish |
Anodizing, electrophoresis, Powder coating; Wooden grain or customize surface treatment |
Anodizing, electrophoresis, Powder coating; Wooden grain or customize surface treatment |
Anodizing, electrophoresis, Powder coating; Wooden grain or surface treatment |
Anodizing, electrophoresis, Powder coating; Wooden grain or customize surface treatment |
