Product Details:

Place of Origin: China,Guangzhou
Brand Name: BUNGE
Certification: ISO9001
Model Number: Series 65 mm folding partition walls

Payment & Shipping Terms:

Minimum Order Quantity: 10 square meters
Price: 92 / 138 dollar per square meter
Packaging Details: Carton package, MDF batten on four section sides ,foam board on both front face.
Delivery Time: Shipped in 10 days after payment, based on the quantity.
Payment Terms: D/A, D/P, L/C, T/T, Western Union, MoneyGram
Supply Ability: 5000 square meters per month
Get Best Price Contact Now

Detail Information

Color: Multi Color Finished: Fabric,leather,laminate
Height: Less Than 4 M Thickness: 65 Mm
Door Material: Aluminium Alloy And MDF Board Application: Hotel,restaurant
Service: OEM Service
High Light:

soundproof folding partition

,

folding room partitions

Product Description

Mdf Board Aluminium Frame Movable Track Soundproof Restaurant Folding Partition Wall



Specification:



Folding partition walls are specified where functional space delineation is an integral element within the partition project. Due to their flexibility and cost effectiveness they allow large rooms to be conveniently sub-divided to maximize space insulation. Principle applications include office interiors, meeting rooms, sports and leisure facilities, schools, colleges, churches, conference and function suites, exhibition centuries, banks and restaurants.



Feature:



Divide the whole area into a number of rooms.


Provide privacy to the inmates from sight and sound.


Are fashionable in design, sizes and finishes customization.


Occupy lesser area.


Ceiling tracks, no floor track.


Sliding and folding.


Easily operate by manual in any position.



Laminate Finished Aluminium Frame Folding Partition Walls For Restaurant 0



Advantage:



Long-term use: with more economy and higher decorative, beautiful and safe, will not scratch the skin.


Cost savings: installation does not affect the construction of smallpox and the ground.


Various forms: optional with a variety of occasions partition wall, can be customized according to customer requirements.


Easy combination: in the re-assembly can make full use of building materials.


Material environmental protection: selection of high-quality melamine particleboard, sound insulation and sealing a good variety of accessories a variety of options.



Folding partition wall track:



Track: The tracks are made from extruded 6063 - T5 anodized aluminium. The track housing shall utilize grooves and interlocking steel pins for positive alignment of adjacent track sections, and shall be reinforced overhead by drop rod brackets. Aluminum track housing shall include an integral nut slot to accept a hardened square nut for attaching each drop rod bracket to the top of the track.



Seals: Vinyl seal of butane rubber will be used as top and bottom and as well as closure seals for the operable wall system.Retractable seal drop will be 22.5 MM or 23 mm.



Laminate Finished Aluminium Frame Folding Partition Walls For Restaurant 1



Technical information:



Series BG65 BG85 BG100
Panel suspension Top hung only Top hung only Top hung only
Track system Single or twin point Single or twin point Single or twin point
Panel thickness 65mm 80mm / 85mm 100mm
Panel height Up to 4000mm Up to 6000mm Up to 18000mm
Max height 4000mm 6000mm 18000mm
Panel width 600-1230mm 600-1230mm 600-1230mm
Frame construction Aluminum frame Aluminum frame Aluminum frame
Face material 9mm 9mm / 12mm 12mm
Fire safety Optional Class I or O Optional Class I or O Optional Class I or O
Vertical profiles Aluminum anodised with sealing profiles Aluminum anodised with sealing profiles Aluminum anodised with sealing profiles
Retractable seals Aluminum black with
double rubber seals
Aluminum black with double rubber seals Aluminum black with double rubber seals
Operation of seals Manual, with supplied
operating handle
Manual, with supplied operating handle Manual, with supplied operating handle
Locking Optional lock to pass doors Optional lock to pass doors Optional lock to pass doors
Pass doors Single open in panel or
double open in two panel
Single open in panel or double open in two panel Single open in panel or double open in two panel
Sound insulation 20-32dB Rw 28-36dB Rw 32-50dB Rw
Weight Approx 22-35kg/sq M Approx 25-40kg/sq M Approx30-48kg/sq M
Finish Material Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized)



Our service:



We design and manufacture value for money products with a one year warranty on all the outstanding ranges illustrated in this brochure.

We offer a complete service package covering site surveys, CAD technical drawings, and quotation presentation. Emphasis is placed on quality assurance backed by a comprehensive after sales service.
