Aluminium Alloy Office Or Conference Room Sliding Partition Walls Customized Size

China Aluminium Alloy Office Or Conference Room Sliding Partition Walls Customized Size supplier
Aluminium Alloy Office Or Conference Room Sliding Partition Walls Customized Size supplier Aluminium Alloy Office Or Conference Room Sliding Partition Walls Customized Size supplier Aluminium Alloy Office Or Conference Room Sliding Partition Walls Customized Size supplier Aluminium Alloy Office Or Conference Room Sliding Partition Walls Customized Size supplier Aluminium Alloy Office Or Conference Room Sliding Partition Walls Customized Size supplier

Large Image :  Aluminium Alloy Office Or Conference Room Sliding Partition Walls Customized Size

Product Details:

Place of Origin: Guangzhou,China
Brand Name: BUNGE
Certification: ASTM E90
Model Number: 65 mm sliding partition walls

Payment & Shipping Terms:

Minimum Order Quantity: No MOQ
Price: US $78-108 per square meter.
Packaging Details: Paper carton,outside with wooden boxes.
Delivery Time: 7-15 days
Payment Terms: T/T, Western Union
Supply Ability: 5000 square meters per month
Contact Now
Detailed Product Description
Feature: Acoustic,sound Proofing Thickness: 65 Mm
Size: Accept Customized Colors: Can Be Customized
Service: Free Sample And Design Width: 800-1220 Mm
Product Name: Sliding Partition Walls Height: 20000-16000 Mm
Open Style: Sliding

Sound Proof Aluminium Alloy Office Wall Partitions,Conference Room Sliding Partition Wall Price

Sliding partition walls details

1) When moving a sliding partition wall panels, there is a 20-25mm gap between the top of the panel and the underside of the head track, there is a similar gap between the bottom of the panel and the floor.



2) Once a sliding partition walls panel is positioned, acoustic integrity is maintained along the top and bottom of the panel by extending pressure seals.



3) The pressure seals are extend and retracted by a single 180 degree turn of removable operating handle.



4) Final Closure of the sliding partition wall is achieved by extending a telescopic sleeve on the last panel. This action simultaneously extends the top and bottom seals.

Aluminium Alloy Office Or Conference Room Sliding Partition Walls Customized Size

Features & Benefits

Top hung system without the need for a floor track.


Retractable top and bottom seals ensure effortless movement of panels.



Combines elegance with robust construction .



Concealed or exposed panel edge profiles.



Numerous panel stacking options for complete flexibility.



Sealed for life roller assemblies provide smooth and silent movement.



The system offers various levels of sound reduction.



Extensive range of surface finishes available.

Acoustics

The monoplane system offers various levels of sound reduction starting at 30dB through to 54 dB. All of these levels have certification awarded by reputable independent acousticians. They are not based "in-house" test. Copies of certification available on request.



Fire Performance



Class "0" or "1" Spread of Flame Panels are available to your requirements.


This type product has 1 hour and 1/2 hour fire assessments.

Aluminium Alloy Office Or Conference Room Sliding Partition Walls Customized Size

Sliding partition walls technical informations



MODEL 65 sliding partition wall 85 sliding partition wall
Panel Thickness 65 mm 85 mm
Panel Width 680mm-1210mm 680mm-1230mm
Panel Hight 2000mm-4500mm 3000mm-6500mm
Frame GB 6063 T6 Aluminium GB 6063 T6 Aluminium

Acoustic alreduction

coefficient(db)

32db 45db

Hermetic flex

distance(mm)

45mm 45mm
Weight(kg/m) 17,19,20,24 24,25,28,38
Panel Material

Class-fibr board,Melamine

decorative lamminate board,

Gypsum board,Color steel plate

,Fiberboard,Tempered glass

Class-fibr board,Melamine

decorative lamminate board,

Gypsum board,Color steel

plate,Fiberboard,Tempered glass

Panel Surface Finish

Anodizing,electrophoresis,

Powder coating; Wooden

grain or customize surface

treatment

Anodizing,electrophoresis,

Powder coating; Wooden

grain or customize surface

treatment

Advantages

65 light-based activities are cut off

cut off,their light weight,flexible

operation,each door can be a

single A hanging round hanging

sliding door can be rotated 360

degrees,or two hanging round

hanging round slide can turn.

85 screen-based activities are better off

cost, weight,moderate and flexible

operation,each door can be a single

hanging round hanging sliding door can

be rotated 360 degrees,or two hanging

round hanging round slide can be Tum

can be pushed to move anywhere.

Slide show steady and smooth

transformation of space diversity.

High degree 2-4.5m 3-6.5m

The largest

rail loading

250kg/m 450kg/m
Usage

Widely used in hotels,guesthouses

and medium-sized exhibition,

multi-functional conference hall.

Widely used in hotels,luxury suites,

function rooms,exhibition center.

Installation methods

slide type, curve type

and folding type.

slide type, curve type

and folding type.

MODEL 100 sliding partition wall Ultrahigh sliding partition wall
Panel Thickness 100 mm 100 mm
Panel Width 680mm-1230mm 680mm-1230mm
Panel Hight 5000mm-8500mm 7000mm-17000mm
Frame GB 6063 T6 Aluminium GB 6063 T6 Aluminium

Acoustic alreduction

coefficient(db)

60db 60db

Hermetic flex

distance(mm)

45mm 60mm
Weight(kg/m) 40,45,48,55 60,60,60,60
Panel Material

Class-fibr board,Melamine

decorative lamminate board

,Gypsum board,Color steel

plate,Fiberboard,Tempered

glass

Class-fibr board,Melamine

decorative lamminate board,

Gypsum board,Color steel plate

,Fiberboard,Tempered glass

Panel Surface

Finish

Anodizing,electrophoresis,

Powder coating; Wooden

grain or customize surface

treatment

Anodizing,electrophoresis,

Powder coating; Wooden

grain or customize surface

treatment

Advantages

100 active partition is partition

noise effect of a good,moderated

360 degrees,or both may be

round hanging Tum can push

the slide to any place.Slide

show steady and smooth

transformation of space diversiyt.

Ultra-high partition screens

employ heavy-duty steel

rails and steel hanging wheels

that the effective sliding

can amount to 100,000

times,which is a leading

technology in partition industry.

High degree 5-8.5m 7-17m

The largest

rail loading

650kg/m 1250kg/m
Usage

Widely used in various

types of training room,a large

hotel,banquet hall.

Widely used in airports

and large exhibition

hall and place.

Installation methods slide type, curve type and folding type. slide type and folding type.
