• Sound Proof MDF Board Movable Partition Walls Exhibition Hall / Ballroom
  • Sound Proof MDF Board Movable Partition Walls Exhibition Hall / Ballroom
  • Sound Proof MDF Board Movable Partition Walls Exhibition Hall / Ballroom
  • Sound Proof MDF Board Movable Partition Walls Exhibition Hall / Ballroom
Sound Proof MDF Board Movable Partition Walls Exhibition Hall / Ballroom

Sound Proof MDF Board Movable Partition Walls Exhibition Hall / Ballroom

Product Details:

Place of Origin: Guangzhou,China
Brand Name: BUNGE
Certification: ASTM E90
Model Number: 65 mm movable partition walls

Payment & Shipping Terms:

Minimum Order Quantity: No MOQ
Price: US $80-108 per square meter.
Packaging Details: Paper carton
Delivery Time: 15-20 days
Payment Terms: T/T, Western Union
Supply Ability: 5000 square meters per month.
Get Best Price Contact Now

Detail Information

Feature: Fireproof And Soundproof Size: Can Be Customized
Thickness: 65 Mm(2 9/16 Inch) Color: Can Be Customized
Flame: Aluminum Materials: Aluminum Frame+MDF
Application: Hotel,restaurant Rail Load: 250-1250 Kg/m
Product Name: Movable Partition Walls
High Light:

movable walls on wheels

,

acoustic movable walls

Product Description

Ballroom Sound Proof MDF Board Acoustic Movable Partition Walls



Movable Partition Walls Details



1. Bunge latest 2014 carrier Dupont POM materials to meet its best wearing resistant, the high carbon chromium bearing steel has reach to a strength 10.9 grade.



2. Bunge patent, vertical crank handle shaft, made by 304 stainless steel ,thick materials.



3. Bunge double corrosion-resistant aluminum track systems are easy to install and easier to maintain. Extruding enable each section to have a uniform for superior end-to-end alignment. Each capacity-certified track is of extrude architectural grade clear anodized 6063-T6 aluminum.


4. Bunge’s patent, 304 stainless steel LCP panel crank handle shaft cup and operable handle.



Product Name
Movable Partition Wall
Installation
Easy Installation , Provide the installation instruction
Material
Melamine , Glass , Fabric , MDF
Application
Meeting room , dining hall , exhibition hall , Function room , office etc.
Color
Multiple colors
Series
65 / 85 / 100 mm
Size
Customized
Type
Sliding doors

Sound Proof MDF Board Movable Partition Walls Exhibition Hall / Ballroom 0



Bunge Movable Partition Walls Systems-Technical Information



Series BG65 BG85 BG100
Panel suspension Top hung only
Track system Single or twin point
Panel thickness 65mm 80mm 100mm
Panel height Up to 3500mm Up to 5200mm Up to 17000mm
Max height 3500mm 5200mm 17000mm
Panel width 600-1230mm 600-1230mm 600-1230mm
Frame construction Aluminum frame
Face material 9mm 9mm / 12mm 12mm
Fire retardant as request
Retractable seals have
Adjustable panels Manual, with supplied operating handle
Pass doors Single door or double door as request
Sound insulation 32dB 40dB 50dB
Weight Approx 22-35kg/sqm Approx 25-40kg/sqm Approx30-48kg/sqm
Finish Material

Plywood, MDF, Laminate, Melamine, Gypsum board,

Fabric, Leather, Insulation board, Fireproof board,

Wall paper, Vinyl, Painting, etc. (Customized)

Sound Proof MDF Board Movable Partition Walls Exhibition Hall / Ballroom 1



Movable Partition Walls Advantages



1> Movable partition wall is modernized decoration style. It can separate the space speedly and conveniently. And it has sound insulation and heat insulation and fireproof function;

2> The movable partition wall is made from high density s/s frame, special made rubber, excellent sound insulation cotton and finish board etc. the finish board is flat and hard;

3> The movable partition wall finish board is inserted in the aluminum track, assembled with multi direction wheels; the board can be stored in may different ways;

4> Movable partition walls doesn’t need track on the floor, we only hang the track on the ceilings and it can be at the same plane with the ceiling decoration. It won’t affect the whole decoration style;

5> Around the board ,there is sound insulation rubber, it can help to insulate the sound entering;

6> The operation ways is much easier, it’s better than the old ways which was use spring before;

7> We can add single or double doors on the board for convenience;

8> We have many different finish to meet customer different requirement and get different decoration effect.

Sound Proof MDF Board Movable Partition Walls Exhibition Hall / Ballroom 2



Movable Partition Walls FAQ



Q1. Can you offer sample?
A: Yes, we could offer free sample, you just need to pay the shipping price.

Q2. What is your terms of payment?
A: T/T 40% as deposit, and 60% before delivery. We'll show you the photos of the products and packages
before you pay the balance.

Q3. What is your terms of delivery?
A: EXW, FOB, CIF.

Q4. How about your delivery time?
A: About 10 working days after receiving your deposit.

Q5. Can you produce according to the samples?
A: Yes, all of our products are customized.


Q6: How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them.
