Aluminium Ceiling Track Acoustic Room Dividers For Classroom / Sliding Partition Walls

China Aluminium Ceiling Track Acoustic Room Dividers For Classroom / Sliding Partition Walls supplier
Aluminium Ceiling Track Acoustic Room Dividers For Classroom / Sliding Partition Walls supplier Aluminium Ceiling Track Acoustic Room Dividers For Classroom / Sliding Partition Walls supplier Aluminium Ceiling Track Acoustic Room Dividers For Classroom / Sliding Partition Walls supplier Aluminium Ceiling Track Acoustic Room Dividers For Classroom / Sliding Partition Walls supplier

Large Image :  Aluminium Ceiling Track Acoustic Room Dividers For Classroom / Sliding Partition Walls

Product Details:

Place of Origin: China,Guangzhou
Brand Name: BUNGE
Certification: ISO9001
Model Number: Series 65 mm acoustic room dividers

Payment & Shipping Terms:

Minimum Order Quantity: 10 square meters
Price: 87 / 136 dollar per square meter
Packaging Details: Carton package, MDF batten on four section sides ,foam board on both front face.
Delivery Time: Shipped in 10 days after payment, based on the quantity.
Payment Terms: D/A, D/P, L/C, T/T, Western Union, MoneyGram
Supply Ability: 5000 square meters per month
Contact Now
Detailed Product Description
Height: Less Than 4 M Thickness: 65 Mm
Surface: Plywood,melamine,leather Open Style: Sliding And Folding
Application: Conference Hall,classroom Position: OEM Service
Color: Multi Color

Aluminium Ceiling Track Acoustic Room Dividers Movable Sliding Wall Partition for Classroom


Specification:

Acoustic room divider is made of high quality anodized aluminum frame with environmentally composite materials.The panels move on a ceiling track with no requirement of floor guides or rails,and they have a standard thickness of 65 mm,85 mm and 100 mm,and a width up to 1230 mm.Maximum height can reach 13 meter tall.

The panel surface will be as per the clients requirement finished either in factory – China or by others . The normal finish such as:laminate,veneer,melamine,fabric etc.

The Panels will be made from MDF boards and shall be 100 mm thick and 1230 mm maximum width, made to the appropriate acoustic rating and structural backing and mounted in full perimeter extruded aluminium frames with interlocking corner construction .The panel faces shall be finished with selected material.

Aluminium Ceiling Track Acoustic Room Dividers For Classroom / Sliding Partition Walls

Feature:
Individual panels that can be stored away for Maximum space usage.
Operable top and bottom seals for effortless operation.
Aluminum frame construction for enhanced acoustics.
The system offers various levels of sound reduction.
Unique track and carrier system ensuring quiet and easy operation.
Numerous panel stacking options for complete flexibility.
Top hanging and no floor track.
Extensive range of surface finishes can be available.
Technical information:


TYPEBG65BG85BG100
Panel suspensionTop hung only
Track systemSingle or twin point
Panel thickness65 mm85 mm100 mm
Panel heightUp to 4000mm,heights greater than 3000mm refer to our technical dept.Up to 6000mm, heights greater than 6000mm refer to our technical dept. Inset passing doors above 2400mm. Full height passing door up to 3000mm high document ‘M’ disabled doors optional.
Max height4000mm6000mm18000mm
Panel width

500 - 1200mm

1' 5/8" -- 4'

500 - 1200mm

1' 5/8" -- 4'

500 - 1200mm

1' 5/8" -- 4'

FrameAluminumAluminumAluminum
Surface material9mm9mm12mm
Fire safetyOptional class IOptional class IOptional class I
Vertical profilesAluminum, anodized with sealing profiles, painter optionalAluminum, anodized with sealing profiles, painter optionalAluminum, anodized with sealing profiles, painter optional
Retractable sealsAluminum, black with double rubber sealsAluminum, black with double rubber sealsAluminum, black with double rubber seals
Operation of sealsManual, with supplied operating handle
LockingOptional lock to passing doors
Passing doorsSingle open in one panel or double open in two panel
Sound insulation32-38dB Rw36-45dB Rw42-55dB Rw
WeightApprox 22-35kg/sq MApprox 25-40kg/sq MApprox 30-48kg/sq M


Aluminium Ceiling Track Acoustic Room Dividers For Classroom / Sliding Partition Walls

Operation:

When the operable seals are retracted, panels glide effortlessly and quietly along the unique aluminium overhead track system (no need for floor guide).
Telescopic end panels enable the wall to be locked off to complete the acoustic seal. The track and carrier system provides ease of operation and directional flexibility, allowing panel stacking in countless configurations.

Our service:

1.Profession--We have professional sales staff. Any questions will be replied within 24 hours.

2.Price--Because we are factory,so we can provide nice quality and lower price products.

Series 65,more than 80 square meters, free sample.

Series 85,quantity up to 120 square meters, extra 20 rollers.

Sereis 100, more than 200 square meters, discount 300 USD.

3.Service--Easy and convenient to transport,we promise timely delivery date, and good after-sale service.

4.Team--We have our own engineering department, according to your request for your tailor-made for your product.

5.Installing--Our engineer can come to teach installing,and we will also supply installing drawings and video.
