Multi Color Commercial Soundproof Office Partition Wall Less Than 4m Height
Product Details:
| Place of Origin: | China,Guangzhou |
| Brand Name: | BUNGE |
| Certification: | ISO9001 |
| Model Number: | Series 65 mm folding partition walls |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10 square meters |
|---|---|
| Price: | 82 / 138 dollar per square meter |
| Packaging Details: | Carton package, MDF batten on four section sides ,foam board on both front face. |
| Delivery Time: | Shipped in 10 days after payment, based on the quantity. |
| Payment Terms: | D/A, D/P, L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 5000 square meters per month |
|
Detail Information |
|||
| Color: | Multi Color | Finished: | Fabric,leather |
|---|---|---|---|
| Height: | Less Than 4 M | Thickness: | 65 Mm |
| Door Material: | Aluminium Alloy+ MDF Board | Application: | Conference Room,classroom |
| Service: | OEM Service | Panel Width: | 800-1200 Mm |
| High Light: | soundproof folding partition,folding room partitions |
||
Product Description
Commercial Soundproof Material Sliding Aluminium Track Office Folding Partition Wall
BUNGE FACTORY OFFER YOU
1: FACTORY DIRECT PRICE.
2: NICE QUALITY.
3: QUICK SHIPPING WITHIN 5 DAYS.
4: SUPPORT CUSTOMER DESIGNS.
5: NO MOQ, SMALL ORDER WELCOME.
6: MORE THAN 3 YEARS WARRANTY.
Specification:
Folding partition wall is a kind of sliding wall that can divide a large space into a small space. It can serve as a multi-purpose room with multiple functions.
Top hanging system without floor track. Also is seal and has good sound insulation.
Our factory can provide four series product let you have a choosing. Panel height is from finished floor to ceiling or beam. Panel width is from wall to wall.
Folding partition wall usually use in banquet hall,conference room,classroom,office and etc.
Our main structure that is aluminium frame with mdf board, inside soundproof rock wool and aluminium keen.
Surface:
Movable partition wall has three kinds surface.
First is mdf melamine,it can be more easy to clean.
Second is leather or fabric with hard cover inside aluminium frame.
Third is leather or fabric with hard cover hidden aluminium frame.
Fourth is mdf bare finish,client can paint prefer color on mdf board in local city.
Also has plywood finish,customers can paste wallpaper on it.
Feature:
No rail suspension:the floor has no track, just install the track on the ceiling.
Stable and safe:Stable and reliable after partitioning, not easy to swing.
Retractable acoustic seals at top and bottom, operated either by quick release handle or semi-automatically with electronic controls.
Sound insulation and environmental protection:sound insulation effect is good,the sound insulation coefficient can reach 53 dB.
Retractable and flexible:the sound proof partitions are freely retractable and flexible, and one person can complete the whole process of partitioning.
Track system:
Tracks: Made of good quality anodized aluminium 6063-T5 materials,hanging the retractable partitions panels with wheels.
Wheels/Rollers: It is the carrier for the retractable partitions,let the panels move more flexibly.Pulley bearing is more than 1600 KGS.
Connectors: Made of anodized aluminium 6063-T5 aluminum tracks,“L”, “T”, “＋”types are available.
Rubber/vinyl seal: Made of Nitrile Butadiene Rubber(NBR+PVC),durable and perfect for sound insulation,wear-resistant.
Rock Wool: Density of 60kg/m3,help us reduce the noise and heat.
Handle: Operate the retractable being up and down.
Retractable mechanism: Control the movement of the top and bottom seal to form a excellent sound insulation performance.
MDF board: 9 mm thickness,density of 760kg/m3,absorbent thickness expansion rate is less than 15%.Formaldehyde emission is 34mg/100g.
Technical information:
| Series | BG65 | BG85 | BG100 |
| Panel suspension | Top hung only | Top hung only | Top hung only |
| Track system | Single or twin point | Single or twin point | Single or twin point |
| Panel thickness | 65mm | 80mm / 85mm | 100mm |
| Panel height | Up to 4000mm | Up to 6000mm | Up to 18000mm |
| Max height | 4000mm | 6000mm | 18000mm |
| Panel width | 600-1230mm | 600-1230mm | 600-1230mm |
| Frame construction | Aluminum frame | Aluminum frame | Aluminum frame |
| Face material | 9mm | 9mm / 12mm | 12mm |
| Fire safety | Optional Class I or O | Optional Class I or O | Optional Class I or O |
| Vertical profiles | Aluminum anodised with sealing profiles | Aluminum anodised with sealing profiles | Aluminum anodised with sealing profiles |
| Retractable seals | Aluminum black with double rubber seals |
Aluminum black with double rubber seals | Aluminum black with double rubber seals |
| Operation of seals | Manual, with supplied operating handle |
Manual, with supplied operating handle | Manual, with supplied operating handle |
| Locking | Optional lock to pass doors | Optional lock to pass doors | Optional lock to pass doors |
| Pass doors | Single open in panel or double open in two panel |
Single open in panel or double open in two panel | Single open in panel or double open in two panel |
| Sound insulation | 20-32dB Rw | 28-36dB Rw | 32-50dB Rw |
| Weight | Approx 22-35kg/sq M | Approx 25-40kg/sq M | Approx30-48kg/sq M |
| Finish Material | Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized) | ||
