Sliding Rail Aluminium Frame Office Acoustic Partition Wall Panel Thickness 65mm
Product Details:
| Place of Origin: | China,Guangzhou |
| Brand Name: | BUNGE |
| Certification: | ISO9001 |
| Model Number: | Series 65 mm acoustic partition wall |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10 square meters |
|---|---|
| Price: | 92 / 126 dollar per square meter |
| Packaging Details: | Carton package, MDF batten on four section sides ,foam board on both front face. |
| Delivery Time: | Shipped in 10 days after payment, based on the quantity. |
| Payment Terms: | D/A, D/P, L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 5000 square meters per month |
|
Detail Information |
|||
| Height: | Less Than 4 M | Width: | 500-1300 Mm |
|---|---|---|---|
| Surface: | Leather | Open Style: | Sliding Folding |
| Function: | Acoustic | Application: | Office,training Room |
| Thickness: | 65 Mm | ||
| High Light: | acoustic operable wall,movable acoustic partition walls |
||
Product Description
Decorative Sliding Rail Aluminium Frame Office Acoustic Partition Wall Panel
Specification:
The acoustic partition is a kind of operable wall that can divide a large space into a small space or a small space into a large space at any time according to needs and has a general wall function. It can serve as a multi-purpose room with multiple functions.
The acoustic partition has the characteristics of easy installation, reliability, industrial production, fire prevention, and environmental protection.
Feature:
1. No need floor suspension: There is no track on the floor, just install the track on the ceiling;
2. Stable and safe: It is stable and reliable after being cut off, and it is not easy to swing;
3. Insulation and energy conservation: excellent insulation performance, according to different seating rates, the large space is divided into small spaces to reduce the air conditioning power consumption;
4.High-efficiency fire prevention: The use of high-efficiency fireproof materials, good fireproof performance;
5. Beautiful and generous: any surface decoration, can be combined with the indoor decoration effect;
6. Retractable and flexible: The partitions move freely, promote flexibility, and one person can complete the entire process of partitioning;
7. Convenient collection: when closing, the partition can be hidden in a dedicated storage cabinet, which does not affect the overall appearance.
Advantage:
Hinged pair panels for quick and easy operation.
Robust aluminum frame construction for demanding environments.
Room divider wide range of surface finishes.
Partial and fully operating panels available.
Partition divider just only top hung supported without floor track.
Technical information:
| TYPE | BG65 | BG85 | BG100 |
| Panel suspension | Top hung only | ||
| Track system | Single or twin point | ||
| Panel thickness | 65 mm | 85 mm | 100 mm |
| Panel height | Up to 4000mm,heights greater than 3000mm refer to our technical dept. | Up to 6000mm, heights greater than 6000mm refer to our technical dept. Inset passing doors above 2400mm. Full height passing door up to 3000mm high document ‘M’ disabled doors optional. | |
| Max height | 4000mm | 6000mm | 18000mm |
| Panel width |
500 - 1200mm 1' 5/8" -- 4' |
500 - 1200mm 1' 5/8" -- 4' |
500 - 1200mm 1' 5/8" -- 4' |
| Frame | Aluminum | Aluminum | Aluminum |
| Surface material | 9mm | 9mm | 12mm |
| Fire safety | Optional class I | Optional class I | Optional class I |
| Vertical profiles | Aluminum, anodized with sealing profiles, painter optional | Aluminum, anodized with sealing profiles, painter optional | Aluminum, anodized with sealing profiles, painter optional |
| Retractable seals | Aluminum, black with double rubber seals | Aluminum, black with double rubber seals | Aluminum, black with double rubber seals |
| Operation of seals | Manual, with supplied operating handle | ||
| Locking | Optional lock to passing doors | ||
| Passing doors | Single open in one panel or double open in two panel | ||
| Sound insulation | 32-38dB Rw | 36-45dB Rw | 42-55dB Rw |
| Weight | Approx 22-35kg/sq M | Approx 25-40kg/sq M | Approx 30-48kg/sq M |
FAQ:
1.How to select the suitable movable wall for your site?
We have 4 types of movable wall, 65 type, 85 type, 100 type and 125 ultra-high type.
2.What you should do on site?
A beam should built on site for track installation. The minimum distance leaving for track installation from false ceiling to top ceiling is 180 mm.
3.How to install?
We will provide the installation manual and video guiding the installation job.We can also dispatch the installation engineer supervising the installation as request.
4.What is lead time?
The lead time is 7 days to 10 days.
5.How to transport?
Sea transport is a common mode of transportation.In an emergency, can be air freight.
6.How do the goods packing?
Carton paper packaging,MDF batten cover all around corner.
The movable wall panel and track,fittings will be packed separately.
7.What is procurement procedure?
Firstly,send us the shop drawings(if the shop drawing is not available, you can tell us the height from false ceiling to finished floor and width from wall to wall).
Secondly, we offer you the movable wall layout drawings for your confirmation.
Thirdly, we quote the movable wall in accordance with confirmed drawings.
8.What is finishing surface?
The bottom panel is MDF or plywood, which is unfinished face.
You can do decoration on site,such as wallpaper,paint,etc.
We can also provide the product with finished face,such as melamine,veneer,acoustic fabric and leather.
Choose from our stylish fabric or leather covers and have the option to have a soft or hard surface.
We can also provide glass partition for glass clip or aluminium frame panel.
