Modern Acoustic Movable Partition Walls / Sliding Folding Partition 3.65 Meters Height
Product Details:
| Place of Origin: | Guangzhou,China |
| Brand Name: | BUNGE |
| Certification: | ISO9001 |
| Model Number: | 65 mm acoustic partition walls |
Payment & Shipping Terms:
| Minimum Order Quantity: | No MOQ |
|---|---|
| Price: | US $80-130 per square meter |
| Packaging Details: | Wooden boxes |
| Delivery Time: | 15-20 days |
| Payment Terms: | T/T |
| Supply Ability: | 5000 square meter per month |
|
Detail Information |
|||
| Feature: | Sound Insulation | Application: | Hotel,banquet Hall |
|---|---|---|---|
| Height: | 3.65 Meters | Product Name: | Acoustic Partition Walls |
| Finish: | Leather,fabric | Thickness: | 65 Mm(2 9/16 Inch) |
| High Light: | acoustic operable wall,movable acoustic partition walls |
||
Product Description
Modern Design Acoustic Movable Partition Walls Sliding Folding Partitions
Specification for BUNGE acoustic partiiton walls: There are wide of range face finishes are available :melamine faced MDF or Plywood,,fabric,carpet,fabric,artificial,leather,wood veneer,high pressure laminate,Formica ,acoustic panel,white boad ect.,panels may also be supplied unfinished for field decoration,Standard frame color is clear anodized aluminum,custom powder coating colors are available.
BUNGE Movable Partition used high density mold- proof, fireproof, enviromental eco-pine wood as base material, processed by full automatic computer controled equipment.
be made to multihole structures product, not only have good sound absorbing effect,
but also looks great on visual.
| Movable Partition | ||||||||
| Basic board | Hoisting weight(kg/m2) | Sound insulation coefficient(db) | Frame material | Retractable range of top/bottom(mm) | Partition Dimension(mm) | |||
| (min/max)width | (min/max)height | Thickness | ||||||
| MGO Board | 24 | 32 | Aluminium | 22.5 | 500-1230 | 2000-4200 | 65 | |
| MDF Board | 24 | |||||||
| MelamineBoard | 24 | |||||||
| MGO Board | 32 | 40 | Aluminium | 22.5 | 500-1231 | 2000-6000 | 85 | |
| MDF Board | 32 | |||||||
| MelamineBoard | 32 | |||||||
| MGO Board | 42 | 50 | Aluminium | 22.5 | 500-1232 | 2000-9000 | 100 | |
| MDF Board | 38 | |||||||
| MelamineBoard | 38 | |||||||
Sound proof partitions technicals
| Description of the whole system | |
| Item | Acoustic partition walls in acoustic fabric |
| Partition Height | From 2 meters to 17 meters. |
| Sound Transmission Class(STC) | From 32db to 56db. |
| Optional Mode | Connected & seperated, sealed & non sealed |
| Description of accessories | |
| Series | Type 65, Type 80, Type 100 |
| Track System | Clear anodized 6063-T6 aluminum track;Imported dupont POM material roller,bearing capacity from 225kg to 250kg. |
| Junction | "T"junction, "L" juntion, cross/ "X" juntion. |
| Finishes | 15mm fabric acoustic panel, Wood veneer, Laminate, Melamine, PU etc.. |
| Product name | Acoustic partition walls |
| Color | Customized |
| Material of Frame | Aluminum Frame |
| Material of Soundproofing | Glass Wool, Steel Plate, Wooden Board |
| Application | restaurant |
| Style | Modern Banquet Hall Folding Partitions |
| Size | Customizied |
| Feature | Assemble |
| Service | OEM ODM Trial |
| Finish | veneer,melamine, fabric or customized |
| Product Keywords | partition wall,wooden room divider,portable divider |
Acoustic partition walls details
1. Overhead Type track: No need to fix floor track, will not destroy the overall decoration effect;
2. Stable and safe: Each partition panel can stand independently, not easy to swing;
3. Soundproofing and Environmental: Effective sound insulation, max acoustic coefficient can be more than 50 dB;
4. Heat Insulation and Energy Save: Good heat-insulating property, can divide large space into small one according to the attendance rate to reduce the air conditioning power consumption;
5. Effective Flame Retardant: Using effective fireproof materials to make better fireproof performance;
6. Elegant Appearance: The sound proof partitions surface decorating can be the same ad the indoor decoration;
7. Retractable and flexible: The sound proof partition is freely retractable and flexible, and one person can complete the whole process of partitioning;
8. Convenient Collecting: Can collect the sound proof partition panels in the cabinet, will not affect the overall view.
9. Wide range of applications: Sound proof partitions can be used in conference halls, exhibition halls, restaurants, high clean factories and offices;
