Payment & Shipping Terms:
|Color:||Multi Color||Finished:||Melamine,plywood,mdf Bare Finish|
|Height:||Less Than 4 M||Thickness:||65 Mm|
|Door Material:||Aluminium Alloy And MDF Board||Application:||Hotel,conference Rooom|
Movable walls are specified where functional space delineation is an integral element within the partition project. Due to their flexibility and cost effectiveness they allow large rooms to be conveniently sub-divided to maximize space insulation. Principle applications include office interiors, meeting rooms, sports and leisure facilities, schools, colleges, churches, conference and function suites, exhibition centuries, banks and restaurants.
1.Space management ~ Movable walls offer an effective space solution for many environments including offices, educational establishments, sporting facilities, dining and entertainment facilities, religious centres, or retail areas.
2.Smart use of space – Movable walls offer a flexible solution for making the most of an interior space. Room sizes can be changed in a matter of moments to capitalise on the revenue potential of commercial space or simply create the most efficient use of floor space.
3.Acoustics ~ the movable wall is the highest specification range of fully operable, individual-panel systems. Acoustic insulation of up to noise reduction is achieved with a combination of acoustic infill’s and operable top and bottom seals.
4.Operation ~ space without a trace ~ when the operable seals are retracted the panels will glide effortlessly and quietly along the unique aluminium overhead track system (no need for floor guide). Final closure of each panel is by a removable operating handle that extends the seal from the top and bottom of each panel forming an acoustic seal.
Movable acoustic wall allow flexible and efficient space utilization combined with excellent acoustic performance in areas such as offices, hotels, exhibition centres, studios and many other applications. With the Acoustic movable walls system, you have a quality, flexible, cost effective solution suitable for most sound-insulated room conceptes.
Panel surfaces from veneer to laminates, enabling us to work with your interior design needs.
Manufactured to meet the acoustic requirements for education installations to school, colleges and Universities are second nature.
Product designed for a quick and easy set up operation.
Each panel is hinged together which allows you to move all the panels in one swift effort. We incorporate an access pass door as standard to give you extra space flexibility.
With each project and opening being different this product is ideal when there is no structural support as this system can be floor supported.
Movable partition is the evolution of operable partition with blind panels and is a perfect acoustic room divider.
It is the answer to all the requirements of a physical, not visual, partition of the spaces and is a perfect acoustic room divider.
Thanks to its silent sliding system, to its thin structure in anodized aluminium and to the simple sliding of the seals, allows a light and transparent closure.
The vertical profiles, studied for the safety control of the inside glazed panels and for the edging of the elements, are coupled with male/female system. The glass (or the covering material) is completely enclosed within the aluminium frame: it is applied to it, not mechanically bound, allowing therefore a wide range of finishings alternatives.
|Panel suspension||Top hung only||Top hung only||Top hung only|
|Track system||Single or twin point||Single or twin point||Single or twin point|
|Panel thickness||65mm||80mm / 85mm||100mm|
|Panel height||Up to 4000mm||Up to 6000mm||Up to 18000mm|
|Frame construction||Aluminum frame||Aluminum frame||Aluminum frame|
|Face material||9mm||9mm / 12mm||12mm|
|Fire safety||Optional Class I or O||Optional Class I or O||Optional Class I or O|
|Vertical profiles||Aluminum anodised with sealing profiles||Aluminum anodised with sealing profiles||Aluminum anodised with sealing profiles|
|Retractable seals||Aluminum black with
double rubber seals
|Aluminum black with double rubber seals||Aluminum black with double rubber seals|
|Operation of seals||Manual, with supplied
|Manual, with supplied operating handle||Manual, with supplied operating handle|
|Locking||Optional lock to pass doors||Optional lock to pass doors||Optional lock to pass doors|
|Pass doors||Single open in panel or
double open in two panel
|Single open in panel or double open in two panel||Single open in panel or double open in two panel|
|Sound insulation||20-32dB Rw||28-36dB Rw||32-50dB Rw|
|Weight||Approx 22-35kg/sq M||Approx 25-40kg/sq M||Approx30-48kg/sq M|
|Finish Material||Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized)|
For single or paired panels up to 250 kg. One 4-wheeled carrier is provided per panel, each wheel is consists of molded polymer tires on hardened steel ball bearings.Resilient mounted body for quite operation and load distribution.special for center stacking option. Usual dimension from the ceiling to the structure is 200 mm.
For Omni-directional panel up to 225 kg. Two carriers are provided per panel. Each carrier has two horizontal counter-rotating wheels that roll (not slide) in the track. Each wheel has precision ground bearings, encased with POM for quiet operation. Carriers easily negotiate square or angled corners without switches. Usual dimension from the ceiling to the structure is 200 mm.
