Payment & Shipping Terms:
|Application:||Conference Room,office||Feature:||Sound Proofing|
|Color:||Accept Customized||Product Name:||Acoustic Room Dividers|
|Style:||Sliding And Folding||Thickness:||85 Mm(3 1/4 Inch)|
Commercial Sliding Folding Partition Walls Acoustic Portable Doors Room Dividers
Bunge Acoustic Room Dividers FAQ
Q:Who We Are?
A:We are the acoustic room dividers for hotel supplier from Guangzhou,China.We have 100% real factory and we have more than 10 years experience in this line.Welcome to visit our factory and showroom.
Q:What is the details about the types of acoustic room dividers?
A:1.Thickness:65 mm,85 mm,100 mm and 125 ultra-high panel.
2.Height:Can be up to 17 meters.
3.Structure:Top hunge system without the need for a floor tracks,only has the ceiling tracks and it will not damage the floor.
4.Panel width:The standard width is about 1000 mm,not over 1200 mm.
Q:What are the finishings about the acoustic room dividers?
A:There are many surfaces for you to choose,such as themelamine,plywood,MDF Board,Natural wood Venner,fabric and the leather surface.In addition,the fabric and the leather surface can be done by soft cover,inside has the sponge.
Q:What is the acoustic roo made of?
A:It is a hanging system.There are many fittings for the acoustic room dividers,such as the tracks,trolley bearings,frames, sealings and so on.Please find the following picture for the whole structure.
Q:How to operate the acoustic room dividers?
A:When moving the acoustic room dividers,there is a 20-25 mm gap between the top of the panel and the underside of the head tracks.Once the panel is posititioned,acoustic integrity is maintained along the top and the bottom of the panels by extending presure seals.It will be operated by a handle.
Q:How we produce the acoustic room dividers and packing them?
A:Actually,each procedure are produced by BUNGE Factory ourselves,including the fittings.Nowadays,we packed the acoustic room dividers via a paper carton,but outside has the wooden boxes,so that the movable partition walls will not damage easily when we deliver to your site.
For further quesitons,please feel free to conact us : Whatsapp: 008613928983277.
Acoustic room dividers technical details:
|Series||BG65||BG80 / BG85||BG100 & BG125|
|Panel suspension||Top hung only||Top hung only||Top hung only|
|Track system||Single or twin point||Single or twin point||Single or twin point|
|Panel thickness||65mm||80mm / 85mm||100mm|
|Panel height||Up to 4000mm||Up to 6000mm||Up to 18000mm|
|Frame construction||Aluminum frame||Aluminum frame||Aluminum frame|
|Face material||9mm||9mm / 12mm||12mm|
|Fire safety||Optional Class I or O||Optional Class I or O||Optional Class I or O|
|Vertical profiles||Aluminum anodised with sealing profiles||Aluminum anodised with sealing profiles||Aluminum anodised with sealing profiles|
|Retractable seals||Aluminum black with
double rubber seals
|Aluminum black with double rubber seals||Aluminum black with double rubber seals|
|Operation of seals||Manual, with supplied
|Manual, with supplied operating handle||Manual, with supplied operating handle|
|Locking||Optional lock to pass doors||Optional lock to pass doors||Optional lock to pass doors|
|Pass doors||Single open in panel or
double open in two panel
|Single open in panel or double open in two panel||Single open in panel or double open in two panel|
|Sound insulation||32-38dB Rw||36-45dB Rw||42-55dB Rw|
|Weight||Approx 22-35kg/sq M||Approx 25-40kg/sq M||Approx30-48kg/sq M|
1. Sound insulation, heat insulation, fireproofing acoustic room dividers.
2. Acoustic room dividers panels help to save space for your building.
3. Our folding room dividers have been installed in many projects around the world.
4. There is no track on the floor. Folding divider is easy to install and disassemble.
5. Single double doors can be made on partition for easy access.
6. Folding partitions acoustic room dividers has beautiful appearance.
7. Commercial folding acoustic room divider is widely used in conference rooms, restaurants, exhibition halls, multi-purpose hall, office and other places.
1. Large selection of standard finish treatments is available for acoustic room dividers.
2. No floor track is needed for wooden folding partition.
3. The acoustic room dividers can be quickly divided by simple pull / latch operation.
4. Retractable top and bottom seals allow easy movement for acoustic room dividers.
5. Tight vertical seal prevents sound leakage and helps align the panel during installation
