MDF + Aluminum Operable Acoustic Movable Office Partition / Wooden Folding Doors
Product Details:
| Place of Origin: | Guangzhou,China |
| Brand Name: | BUNGE |
| Certification: | ISO 9001 |
| Model Number: | 85 mm |
Payment & Shipping Terms:
| Minimum Order Quantity: | 20 square meters |
|---|---|
| Price: | US $76-138 per square meter |
| Packaging Details: | Carton package, MDF batten on four section sides , foam board on both front face. |
| Delivery Time: | 15-25 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 5000 square meter per month |
|
Detail Information |
|||
| Product Name: | Folding Partition Walls | Color: | Customized |
|---|---|---|---|
| Material: | MDF+Aluminum | Panel Width: | 500 Mm--1230 Mm |
| Finish: | Melamine | Feature: | Sound Proofing |
| High Light: | acoustic operable partitions,acoustic operable wall |
||
Product Description
Movable Office Partitions Folding Wooden Doors Operable Acoustic Partition Walls
Features of Acoustic Partition Walls
1. No need floor suspension: There is no track on the floor, just install the track on the ceiling;
2. Stable and safe: It is stable and reliable after being cut off, and it is not easy to swing;
3. Soundproof and environmental protection: sound insulation effect is good, the maximum sound insulation coefficient can reach 53dB;
4. Insulation and energy conservation: excellent insulation performance, according to different seating rates, the large space is divided into small spaces to reduce the air conditioning power consumption;
5.High-efficiency fire prevention: The use of high-efficiency fireproof materials, good fireproof performance.
Action Now:
1:Buy 30 square meters Get 5% Discount.
2:Buy 80 square meters Get 10% Discount.
3:Get a FREE SAMPLE.
4:Support a 3 YEARS WARRANTY.
5:Contact us for more details-Whatsapp:008613928983277.
Bunge Movable Partition Products as follow:
1. Ordinary Type : 65, 85; 100;
2. High Sound Proof Type: 85, 100;
3. Heavy Duty Type : 100, 125SH;
4. Glass Type: 65 (Glass Clip); 65 & 85(Aluminium Frame).
Specifications of Folding Partition Walls System
| Model | BG65 Series | BG85 Series | BG100 Series | BG High-Series | |
| Suspensionsystem | Aluminum hanging | Steal Hanging | |||
| Basic Thickness | 65 mm | 85 mm | 100 mm | 100 mm | |
| Total thickness | 65/75/85/95mm | 85/90/100/110mm | 100/120/130mm | 100/120/130mm | |
| Max Height | Up to 3800 mm | Up to 6000 mm | Up to 8000 mm | Up to 15000 mm | |
| Width | 600-1230mm | 600-1230mm | 800-1230mm | 800-1230mm | |
| Floor/Ceiling Sealing Strength | Telescopic aluminum tube with rubber strip. | ||||
| Side walls sealing strength | Double seal tape | ||||
| Sound insulation level | 26-30 db | 28-34 db | 32-40 db | 42-52 db | |
| Panel structure | Aluminum frame with wooden keel | Aluminum frame with steel keel | |||
| Surface material | Melamine laminate/fabric/PU leather/wallpaper/veneer/customized | ||||
How to order the acoustic partition walls
Step 1: Send an inquiry to us.
Step 2: Send detailed project drawings or dimensions to us.
Step 3: We provide the solution and quotation.
Step 4: Negotiation and details discussion.
Step 5: Place order and arrange deposit.
Step 6: Make detailed shop drawing for approval before production.
Step 7: Arrange production after the shop drawing confirmed.
Step 8: Quality control and Inspection.(Production pictures will be provided for checking).
Step 9: Arrange balance.
Step 10:Arrange shipping after received the balance.
Step 11:Provide shop drawing for installation.
Step 12: After sales
