Custom Color Acoustic Office Partition Wall / Sliding Door Wooden Folding Partition Doors

Custom Color Acoustic Office Partition Wall / Sliding Door Wooden Folding Partition Doors

Product Details:

Place of Origin: China,Guangzhou
Brand Name: BUNGE
Certification: ISO9001
Model Number: Series 65 mm folding partition wall

Payment & Shipping Terms:

Minimum Order Quantity: 10 square meters
Price: 91/135 dollar per square meter
Packaging Details: Carton package, MDF batten on four section sides ,foam board on both front face.
Delivery Time: Shipped in 10 days after payment, based on the quantity.
Payment Terms: D/A, D/P, L/C, T/T, Western Union, MoneyGram
Supply Ability: 5000 square meters per month
Get Best Price Contact Now

Detail Information

Finished: Pu Leather,mdf Melamine Height: Less Than 4 M
Structure: Aluminium Frame And Mdf Board Sliding Door Type: Sliding Doors
Product Name: Folding Partition Wall Thickness: 85 Mm
Application: Office,classroom
High Light:

soundproof folding partition

,

folding room partitions

Product Description

Custom Color Acoustic Office Partition Wall / Sliding Door Wooden Folding Partition Doors

Acoustic Sliding Door Wooden Partition Folding Office Partition Wall Panel



Specification:



Folding partition walls are the standard product to use when dividing classrooms, training rooms, ball rooms, and gymnasiums. BUNGE offers several models including steel framed panel, steel reinforced frames, hinged pair panels, individual panels, curve & diver and electric wall type systems. BUNGE 's operable partitions are tested to high quality standards with life cycle, stress, and serviceability of the panels for our distributors and customers.



Folding Partition Wall Feature:



Stable and self-supporting frame construction.


Flexibility through wide variety of panel arrangements.


Ease of use & movement due to light in construction.


Smooth and silent while in operation.


Good acoustic performance.


Availability of unlimited choice of finishes.



Custom Color Acoustic Office Partition Wall / Sliding Door Wooden Folding Partition Doors 0



Technical information:



Series BG65 BG85 BG100
Panel suspension Top hung only Top hung only Top hung only
Panel thickness 65 mm 85 mm 100 mm
Max height 4000 mm 6000 mm 18000 mm
Panel width 500-1200 mm 500-1200 mm 500-1200 mm
Face material 9 mm 9 mm 12 mm
Pass doors Single door or Double door
Sound insulation 20-32dB Rw 28-36dB Rw 32-50dB Rw



Finish Material

Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized)



Advantage:



Room to move, room to work or play. Public meeting or private function, assembly or seminar: Movable Acoustic Walls and Sliding Folding Partitions put all the options at your fingertips.



Gliding effortlessly along a concealed track suspended above the ceiling, our movable walls can provide all the acoustic and aesthetic qualities of a fixed wall, with the immeasurable advantage of maximum flexibility.

A variety of configurations and divisions can be achieved easily and rapidly. Once in place, spring loaded seals lock the panels into position.



Custom Color Acoustic Office Partition Wall / Sliding Door Wooden Folding Partition Doors 1



Track system:



For single or paired panels up to 250 kg. One 4-wheeled carrier is provided per panel, each wheel is consists of molded polymer tires on hardened steel ball bearings.Resilient mounted body for quite operation and load distribution.special for center stacking option. Usual dimension from the ceiling to the structure is 200 mm.



Our service:



We design and manufacture value for money products with a one year warranty on all the outstanding ranges illustrated in this brochure.



We offer a complete service package covering site surveys, CAD technical drawings, and quotation presentation. Emphasis is placed on quality assurance backed by a comprehensive after sales service.
