Movable Track Office Partition Wall Fabric Surface Aluminium Folding Door System
Product Details:
| Place of Origin: | China,Guangzhou |
| Brand Name: | BUNGE |
| Certification: | ISO9001 |
| Model Number: | Series 85 mm sliding partition wall |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10 square meters |
|---|---|
| Price: | 91 /136 dollar per square meter |
| Packaging Details: | Carton package, MDF batten on four section sides ,foam board on both front face. |
| Delivery Time: | Shipped in 10 days after payment, based on the quantity. |
| Payment Terms: | T/T, Western Union, MoneyGram |
| Supply Ability: | 5000 square meters per month |
|
Detail Information |
|||
| Application: | Office,classroom,conference Room | Height: | Less Than 6 M |
|---|---|---|---|
| Material: | MDF Board+Aluminium | Thickness: | 85 Mm |
| Color: | Multi Color | Open Style: | Folding And Sliding |
| Width: | 800-1300 Mm | ||
| High Light: | sliding folding partition,sound proof sliding partitions |
||
Product Description
Aluminium Folding Door System Movable Track Office Sliding Wall Partitions
Description:
Sliding partition wall is a top hung movable acoustic wall of lighter construction made up of individual panels designed to give economical but strong and long lasting use in the division of space requiring flexibility and offers good levels of sound reduction and high quality finish.
It is ideal for use in meeting rooms, classrooms, church halls and offices. Panels can be finished in priming sheet for client decoration, standard factory finish in standard laminate or spray paint, textile coverings, full range of veneers and laminates or to suit clients requirements.
Technical information:
| Series | BG65 | BG85 | BG100 |
| Panel suspension | Top hung only | Top hung only | Top hung only |
| Panel thickness | 65 mm | 85 mm | 100 mm |
| Max height | 4000 mm | 6000 mm | 18000 mm |
| Panel width | 500-1200 mm | 500-1200 mm | 500-1200 mm |
| Face material | 9 mm | 9 mm | 12 mm |
| Pass doors | Single door or Double door | ||
| Sound insulation | 20-32dB Rw | 28-36dB Rw | 32-50dB Rw |
|
Finish Material |
Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized) | ||
Advantage:
Sliding acoustic partition wall allow flexible and efficient space utilization combined with excellent acoustic performance in areas such as offices, hotels, exhibition centres, studios and many other applications. With the Acoustic movable walls system, you have a quality, flexible, cost effective solution suitable for most sound-insulated room concepts.
Panel surfaces from veneer to laminates, enabling us to work with your interior design needs.
Product designed for a quick and easy set up operation.
Each panel is hinged together which allows you to move all the panels in one swift effort. We incorporate an access pass door as standard to give you extra space flexibility.
Feature:
Top hung with no floor track required.
Retractable acoustic seals at top and bottom of each panel operated either by a quick release handle.
Single or twin point suspension for central or offset stacking options.
Variable track arrangements.
Junction panels enable corner, three or four way abutments.
Panel finishes include Melamine Laminate, Veneer, Vinyl, Whiteboard or Painted.
Optional inset pass doors, fully glazed panels and vision panels.
Closure panel fitted with face operated telescopic "nose".
Sliding partition wall benifits:
Hinged pair panels for quick andeasy operation.
Robust aluminum frame construction for demanding environments.
Room divider wide range of surface finishes.
Partial and fully operating panels available.
Parition divider just only top hung supported without floor track.
Our service:
We design and manufacture value for money products with a one year warranty on all the outstanding ranges illustrated in this brochure.
We offer a complete service package covering site surveys, CAD technical drawings, and quotation presentation. Emphasis is placed on quality assurance backed by a comprehensive after sales service.
