Product Details:

Place of Origin: China,Guangzhou
Brand Name: BUNGE
Certification: ISO9001
Model Number: Series 85 mm sliding partition wall

Payment & Shipping Terms:

Minimum Order Quantity: 10 square meters
Price: 86 /124 dollar per square meter
Packaging Details: Carton package, MDF batten on four section sides ,foam board on both front face.
Delivery Time: Shipped in 10 days after payment, based on the quantity.
Payment Terms: D/A, D/P, L/C, T/T, Western Union, MoneyGram
Supply Ability: 5000 square meters per month
Get Best Price Contact Now

Detail Information

Application: Restaurant,banquet Hall Height: Less Than 6 M
Material: Aluminium Frame And Mdf Board Thickness: 85 Mm
Service: OEM Service Open Style: Folding And Sliding
High Light:

sliding folding partition

,

sound proof sliding partitions

Product Description

Portable Soundproof Material Ceiling Haning Restaurant Sliding Partition Wall



Description:



The soundproof partition is also called activity partition, which can be called partition, mobile screen, event display board, activity screen, mobile partition wall, and track partition. The movable partition has the characteristics of easy installation, reliability, industrial production, fire prevention, and environmental protection.



Soundproof partition wall brings a lot of convenience to people's work. For example, when you need it, you can fold it on one side to make the two spaces fit together and appear larger. This facilitates temporary departmental meetings. For another example, the activities are highly partitioned. Generally, our company's factory may be rented. For various reasons, we have to change places.



Technical information:



Series BG65 BG85 BG100
Panel suspension Top hung only Top hung only Top hung only
Panel thickness 65 mm 85 mm 100 mm
Max height 4000 mm 6000 mm 18000 mm
Panel width 500-1200 mm 500-1200 mm 500-1200 mm
Face material 9 mm 9 mm 12 mm
Pass doors Single door or Double door
Sound insulation 20-32dB Rw 28-36dB Rw 32-50dB Rw



Finish Material

Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized)



Portable Ceiling Haning Restaurant Partition Wall Panel Height 4m ISO9001 0



Structure:



Our soundproof sliding partition system accessories are custom for each client and project,and they are also made of superior material.Track system for right-angled configurations with cross- roller carriers for element weights up to 500 kg. Support rollers in the junctions guarantee easy operation when sliding the elements across intersections .



Surface:



1. The partition wall of the movable partition series consists of melamine board, fire board, color steel plate, gypsum board and other decorative materials.


2.The heart is made of aluminum alloy frame and steel with fire, moisture, noise, environmental protection, non-deformation and other functions, in the hotel partition layout, color and surface decoration, etc. to maintain the hotel after the partition is simple and exquisite, durable and flexible use Diversified spaces and very stylish hotel interior style after partition.



Portable Ceiling Haning Restaurant Partition Wall Panel Height 4m ISO9001 1



Installing sliding aluminium track:



1. When the partition is hung on the track, escape exit tracks can be removed without rebuilding the crane.


2. For the escape exit track must be a special bracket track connection.


3. When installing the track, perform the construction according to the accurate data of the adjustment during the measurement.



Our service:



We offer quality, reliable solutions with partitions and movable walls and passing doors, security grilles, and wood roll-up doors and shutters. We provide pricing, technical assistance, installation and design options for General Contractors, Architects, and Interior Designers.
