Sound Proof Sliding Alumninium Track Roller Restaurant Partition Wall Panel Height 4m Commercial Furniture
Product Details:
| Place of Origin: | China,Guangzhou |
| Brand Name: | BUNGE |
| Certification: | ISO9001 |
| Model Number: | Series 85 mm sound proof partitions |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10 square meters |
|---|---|
| Price: | 107 / 135 dollar per square meter |
| Packaging Details: | Carton package, MDF batten on four section sides ,foam board on both front face. |
| Delivery Time: | Shipped in 10 days after payment, based on the quantity. |
| Payment Terms: | D/A, D/P, L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 5000 square meters per month |
|
Detail Information |
|||
| Service: | OEM Service | Surface: | Mdf Melamine,fabric |
|---|---|---|---|
| Application: | Restaurant,banquet Hall | Height: | Less Than 6 M |
| Color: | Multi Color | Thickness: | 85 Mm |
| Open Style: | Folding | Width: | 800-1200 Mm |
| High Light: | sounproof folding partition,movable soundproof partition |
||
Product Description
Commercial Furniture Sliding Alumninium Track Roller Restaurant Soundproof Partition Wall
Description:
Our soundproof partition system accessories are custom for each client and project,and they are also made of superior material.Track system for right-angled configurations with cross- roller carriers for element weights up to 500 kg. Support rollers in the junctions guarantee easy operation when sliding the elements across intersections .
Besides the high sound absorbing test,we have passed the Eco-protection test and Fireproof test,to ensure you to get the top quality product, and enjoy a safe , comfortable and low carbon emission way of life on movable and operable partition system.
Benefits:
Individually operated, top hung panels, purpose made to suit any opening size up to 10 metres high.
Retractable top and bottom seals, able to deal with floor level differences up to 22.5 mm.
Mechanically operated by worm screw drive providing 2Kn of pressure for optimal acoustic performance.
No floor track.
Curved layouts, corner panels, junction panels, glazing cutouts, matching recess doors to special order.
Suitable for internal use only with a wide variety of features and finishes.
Surface treatment:
The standard colour for the track profile of the folding wall and the jamb profiles is white and the panels edge profiles are natural anodized.
There is a wide variety of panel surface treatments.
As a special solution it is possible to install a glass opening in the center of the panel. The opening can cover the whole panel, the bottom or the top.
Technical information:
| Panel Suspension | Top hanging system without the need for a floor track. |
| Panel Width | Each panel 600mm-1200mm. |
| Track | Aluminum Or Steel Track |
| Roller on panel | Single or Double Roller |
| Panel Frames | Heavy-duty steel-gusseted aluminum inner frames reinforced with full height. |
| Top and bottom seals | Top and bottom pressure retractable seals ensure effortless moved and locked. |
| Module | 700mm - 1200mm maximum. |
| Panel stacking | Numerous panel stacking options for complete flexibility. |
| Panel Surface | MDF,Plywood, woven fabric, Leather,Natural wood veneer, Melamine,Wood moldings, etc. |
| Finishes | Satin anodized or polyester powder coating to all exposed aluminium components available in a wide range of colour as standard. |
Track system details:
For single or paired panels up to 250 kg. One 4-wheeled carrier is provided per panel, each wheel is consists of molded polymer tires on hardened steel ball bearings.Resilient mounted body for quite operation and load distribution.special for center stacking option. Usual dimension from the ceiling to the structure is 200mm.
For Omni-directional panel up to 225 kg. Two carriers are provided per panel. Each carrier has two horizontal counter-rotating wheels that roll (not slide) in the track. Each wheel has precision ground bearings, encased with POM for quiet operation. Carriers easily negotiate square or angled corners without switches. Usual dimension from the ceiling to the structure is 200 mm.
We can offer:
A full professional design service.
Survey and installation guide.
Using top quality materials and components.
A fully experienced work team.
Maintenance contracts to ensure your valuable asset remains in full work order.
