Product Details:

Place of Origin: China
Brand Name: BUNGE
Certification: ISO 9001
Model Number: 85 mm acoustic partition walls

Payment & Shipping Terms:

Minimum Order Quantity: 10 square meters
Price: US Dollars $ 82 / 125 per square meter
Packaging Details: Carton package, MDF batten on four section sides ,foam board on both front face.
Delivery Time: 10-25 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 5000 square meters per month
Get Best Price Contact Now

Detail Information

Color: Accept Customized Thickness: 85 Mm
Feature: Sound Insulation Height: 4 Meters
Surface: Melamine Produce Name: Acoustic Partition Walls
High Light:

acoustic operable partitions

,

movable acoustic partition walls

Product Description

Banquet Hall Landscaping Leather Finishes Sliding Hotel Acoustic Partition Walls

Product Details of Acoustic Partition Walls

We design and manufacture value for many products with one year's warranty on all the outstanding ranges illustrated in this brochure.


They offer a complete service package covering site surveys, CAD technical drawings, and quotation presentation. Emphasis is placed on quality assurance backed by a comprehensive after sales service.



Acoustic partition walls are specified where functional space delineation is an integral element within the partition project. Due to their flexibility and cost effectiveness they allow large rooms to be conveniently sub-divided to maximise space utilisation. Principle applications include office interiors, meeting rooms, sports and leisure facilities, schools, colleges, churches,conference and function suites, exhibition centres,banks and restaurants.



Acoustic partition wall is a kind of activity wall that can divide a large space into a small space, or a small space into a large space at any time,according to needs, and has a general wall function. It can serve as a multi-purpose room with multiple functions.

Hotel Banquet Hall Acoustic Partition Walls Landscaping Leather Finishes ISO 9001 0

Acoustic Partition Walls System-Technical Information

TYPE 65A 85A 100A&125A
Panel suspension Top hung only Top hung only Top hung only
Track system Single or twin point Single or twin point Single or twin point
Panel thickness 65mm 85mm 100mm
Panel height Up to 4000mm,Heights greater than 3000mm refer to our Technical Dept Up to 6000mm,Heights greater than 6000mm refer to our Technical Dept.inset Pass doors above 2400mm.Full Height pass door up to 3000mm high Document 'M'disabled doors-optional
Max height 4000mm with heavy duty track 6000mm with heavy duty track 18000mm with heavy duty track or steel track
Panel width 600-1200mm 600-1200mm 600-1200mm
Frame construction Aluminium/steel Aluminium/steel Aluminium/steel
Face material 12mm 12/15/18mm 12/15/18mm
Fire safety optional Class I or O optional Class I or O optional Class I or O
Vertical profiles Aluminium,anodised with sealing profiles,painted-optional Aluminium,anodised with sealing profiles,painted-optional Aluminium,anodised with sealing profiles,painted-optional
Retractable seals Aluminium,black with double rubber seals Aluminium,black with double rubber seals Aluminium,black with double rubber seals
Operation of seals Manual,with supplied operating handle Manual,with supplied operating handle Manual,with supplied operating handle
Locking Optional lock to pass doors Optional lock to pass doors Optional lock to pass doors
Pass Doors Single open in oanel or double open in two panel Single open in oanel or double open in two panel Single open in oanel or double open in two panel
Sound insulation 40,44,47,50dB Rw 40,44,47,50,53dB Rw 40,44,47,50,53,58dB Rw
Weight Approx 33-40kg/sq M Approx 43-50kg/sq M Approx 63-70kg/sq M

Hotel Banquet Hall Acoustic Partition Walls Landscaping Leather Finishes ISO 9001 1

FAQ of Acoustic Partition Walls

Q1. Can I have a sample order for acoustic partition walls

Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.

Q2. What about the lead time?

Sample needs 3-5 days, mass production time needs 10-20 days for order quantity more than 300 square meter

Q3. Do you have any MOQ limit for partition order?

Low MOQ, 20 square meter, because its big size and volume

Q4. How do you ship the samples and how long does it take to arrive?

We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.

Q5. Do you provide installation?

We provide installation guide, in general, we send two person for installation instructions on site, customer need cover tickets, hotels, accommodations, 120-200USD one person per day for instructions

Q6. Is it OK to print my logo on packing?

Yes. Please inform us formally before our production and confirm the design firstly based on our sample.

Q7: Do you offer guarantee for the products?

Yes, we offer one years warranty to our products.
