Hotel Banquet Hall Acoustic Partition Walls Landscaping Leather Finishes ISO 9001
Product Details:
Place of Origin: | China |
Brand Name: | BUNGE |
Certification: | ISO 9001 |
Model Number: | 85 mm acoustic partition walls |
Payment & Shipping Terms:
Minimum Order Quantity: | 10 square meters |
---|---|
Price: | US Dollars $ 82 / 125 per square meter |
Packaging Details: | Carton package, MDF batten on four section sides ,foam board on both front face. |
Delivery Time: | 10-25 days |
Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Supply Ability: | 5000 square meters per month |
Detail Information |
|||
Color: | Accept Customized | Thickness: | 85 Mm |
---|---|---|---|
Feature: | Sound Insulation | Height: | 4 Meters |
Surface: | Melamine | Produce Name: | Acoustic Partition Walls |
High Light: | acoustic operable partitions,movable acoustic partition walls |
Product Description
Banquet Hall Landscaping Leather Finishes Sliding Hotel Acoustic Partition Walls
Product Details of Acoustic Partition Walls
We design and manufacture value for many products with one year's warranty on all the outstanding ranges illustrated in this brochure.
They offer a complete service package covering site surveys, CAD technical drawings, and quotation presentation. Emphasis is placed on quality assurance backed by a comprehensive after sales service.
Acoustic partition walls are specified where functional space delineation is an integral element within the partition project. Due to their flexibility and cost effectiveness they allow large rooms to be conveniently sub-divided to maximise space utilisation. Principle applications include office interiors, meeting rooms, sports and leisure facilities, schools, colleges, churches,conference and function suites, exhibition centres,banks and restaurants.
Acoustic partition wall is a kind of activity wall that can divide a large space into a small space, or a small space into a large space at any time,according to needs, and has a general wall function. It can serve as a multi-purpose room with multiple functions.
Acoustic Partition Walls System-Technical Information |
|||
TYPE | 65A | 85A | 100A&125A |
Panel suspension | Top hung only | Top hung only | Top hung only |
Track system | Single or twin point | Single or twin point | Single or twin point |
Panel thickness | 65mm | 85mm | 100mm |
Panel height | Up to 4000mm,Heights greater than 3000mm refer to our Technical Dept | Up to 6000mm,Heights greater than 6000mm refer to our Technical Dept.inset Pass doors above 2400mm.Full Height pass door up to 3000mm high Document 'M'disabled doors-optional | |
Max height | 4000mm with heavy duty track | 6000mm with heavy duty track | 18000mm with heavy duty track or steel track |
Panel width | 600-1200mm | 600-1200mm | 600-1200mm |
Frame construction | Aluminium/steel | Aluminium/steel | Aluminium/steel |
Face material | 12mm | 12/15/18mm | 12/15/18mm |
Fire safety | optional Class I or O | optional Class I or O | optional Class I or O |
Vertical profiles | Aluminium,anodised with sealing profiles,painted-optional | Aluminium,anodised with sealing profiles,painted-optional | Aluminium,anodised with sealing profiles,painted-optional |
Retractable seals | Aluminium,black with double rubber seals | Aluminium,black with double rubber seals | Aluminium,black with double rubber seals |
Operation of seals | Manual,with supplied operating handle | Manual,with supplied operating handle | Manual,with supplied operating handle |
Locking | Optional lock to pass doors | Optional lock to pass doors | Optional lock to pass doors |
Pass Doors | Single open in oanel or double open in two panel | Single open in oanel or double open in two panel | Single open in oanel or double open in two panel |
Sound insulation | 40,44,47,50dB Rw | 40,44,47,50,53dB Rw | 40,44,47,50,53,58dB Rw |
Weight | Approx 33-40kg/sq M | Approx 43-50kg/sq M | Approx 63-70kg/sq M |
FAQ of Acoustic Partition Walls
Q1. Can I have a sample order for acoustic partition walls
Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What about the lead time?
Sample needs 3-5 days, mass production time needs 10-20 days for order quantity more than 300 square meter
Q3. Do you have any MOQ limit for partition order?
Low MOQ, 20 square meter, because its big size and volume
Q4. How do you ship the samples and how long does it take to arrive?
We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
Q5. Do you provide installation?
We provide installation guide, in general, we send two person for installation instructions on site, customer need cover tickets, hotels, accommodations, 120-200USD one person per day for instructions
Q6. Is it OK to print my logo on packing?
Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
Q7: Do you offer guarantee for the products?
Yes, we offer one years warranty to our products.
