Aluminum - Framed Acoustic Room Dividers Partitions For Multi - Purpose Hall

Good quality Movable Partition Walls for sales
Good quality Movable Partition Walls for sales
We had installed the partition wall - it worked out well and our customer is happy. So we would like to thank you for delivering high quality goods an

—— Frank

I am so glad to cooperate with Bunge. Their products with good quality and pretty competitive price. My customers like it very much.

—— Grace

We have a lot of business with Bunge since 2011 ,I hope we have more orders and they continue to give our best service and quality.

—— Roger

Bunge is very serious and responsible supplier , partition walls have good quality and high sound proof .

—— Charles

I'm Online Chat Now

Aluminum - Framed Acoustic Room Dividers Partitions For Multi - Purpose Hall

China Aluminum - Framed Acoustic Room Dividers Partitions For Multi - Purpose Hall supplier
Aluminum - Framed Acoustic Room Dividers Partitions For Multi - Purpose Hall supplier Aluminum - Framed Acoustic Room Dividers Partitions For Multi - Purpose Hall supplier Aluminum - Framed Acoustic Room Dividers Partitions For Multi - Purpose Hall supplier Aluminum - Framed Acoustic Room Dividers Partitions For Multi - Purpose Hall supplier

Large Image :  Aluminum - Framed Acoustic Room Dividers Partitions For Multi - Purpose Hall

Product Details:

Place of Origin: China
Brand Name: BUNGE
Certification: ISO 9001
Model Number: 85 mm acoustic room dividers

Payment & Shipping Terms:

Minimum Order Quantity: 10 square meters
Price: US Dollars $ 75 / 125 per square meter
Packaging Details: Carton package, MDF batten on four section sides ,foam board on both front face.
Delivery Time: 10-25 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 5000 square meters per month
Contact Now
Detailed Product Description
Color: Accept Customized Thickness: 85 Mm
Feature: Sound Insulation Product Name: Acoustic Room Dividers
Height: 6 Meters Surface: Melamine

Operable Wall Partitions,Movable Acoustic Room Dividers for Multi-Purpose Hall



Features about Acoustic Room Dividers



Acoustic room dividers are specified where functional space delineation is an integral element within the partition project. Due to their flexibility and cost effectiveness they allow large rooms to be conveniently sub-divided to maximise space utilisation. Principle applications include office interiors, meeting rooms, sports and leisure facilities, schools, colleges, churches, conference and function suites, exhibition centres, banks and restaurants.



We design and manufacture value for many products with one year's warranty on all the outstanding ranges illustrated in this brochure. We offer a complete service package covering site surveys, CAD technical drawings, and quotation presentation. Emphasis is placed on quality assurance backed by a comprehensive after sales service.



The acoustic room divider is aluminum-framed operable partition is the most versatile operable wall constructed today. Acoustic room dividers are a series of flat panels, approximately range from 600mm(23") to 1200mm(47") wide. They have a wide array of features and options to meet most design and budget requirements. Models are acoustically rated, available in 65mm(2.6") ,80mm(3")or 100mm(4") thick models, and in single, pair hinged configurations.

Aluminum - Framed Acoustic Room Dividers Partitions For Multi - Purpose Hall

Technical Information:



MODEL 65 sliding partition wall 85 sliding partition wall
Panel Thickness 65mm 85mm
Panel Width 680mm-1210mm 680mm-1230mm
Panel Hight 2000mm-4500mm 3000mm-6500mm
Frame GB 6063 T6 Aluminium GB 6063 T6 Aluminium

Acoustic alreduction

coefficient(db)

32db 45db

Hermetic flex

distance(mm)

45mm 45mm
Weight(kg/m) 17,19,20,24 24,25,28,38
Panel Material

Class-fibr board,Melamine

decorative lamminate board,

Gypsum board,Color steel plate

,Fiberboard,Tempered glass

Class-fibr board,Melamine

decorative lamminate board,

Gypsum board,Color steel

plate,Fiberboard,Tempered glass

Panel Surface Finish

Anodizing,electrophoresis,

Powder coating; Wooden

grain or customize surface

treatment

Anodizing,electrophoresis,

Powder coating; Wooden

grain or customize surface

treatment

Advantages

65 light-based activities are cut off

cut off,their light weight,flexible

operation,each door can be a

single A hanging round hanging

sliding door can be rotated 360

degrees,or two hanging round

hanging round slide can turn.

85 screen-based activities are better off

cost, weight,moderate and flexible

operation,each door can be a single

hanging round hanging sliding door can

be rotated 360 degrees,or two hanging

round hanging round slide can be Tum

can be pushed to move anywhere.

Slide show steady and smooth

transformation of space diversity.

High degree 2-4.5m 3-6.5m

The largest

rail loading

250kg/m 450kg/m
Usage

Widely used in hotels,guesthouses

and medium-sized exhibition,

multi-functional conference hall.

Widely used in hotels,luxury suites,

function rooms,exhibition center.

Installation methods

slide type, curve type

and folding type.

slide type, curve type

and folding type.



Acoustic room dividers parking layout:

Aluminum - Framed Acoustic Room Dividers Partitions For Multi - Purpose Hall



FAQ of Acoustic Room Dividers


How to select the suitable acoustic room dividers for your site?


We have 4 types of acoustic room dividers,65type,80type,100type and 125 ultra-high type. You can choose the right movable wall upon the Height and Soundproof requirement as following,


65type-- Max height 3.5m, soundproof: 38dB to 43dB


85type- Max height:5.5m,Soundproof: 43dB to 53dB


100type--- Max height:7m,Soundproof: 43dB to 58dB


125ultra-height---Max height:17m,Soundproof: 38dB to 48dB

What you should do on site?


A beam(truss) should built on site for track installation.The min distance leaving for track installation from false ceiling to top ceiling is 200mm.

How to install?


We will provide the installation manual and video guiding the installation job. We can also dispatch the installation engineer supervising the installation as request.

What is lead time?


The lead time is 7 days to 10 days.

How to transport?


Sea transport is a common mode of transportation. In an emergency, can be air freight.

How do the goods packing?


corrugating paper packaging, MDF batten cover all around corner.
The movable wall panel and track, fittings will be packed separately.

What is Procurement procedure?


Firstly, send us the shop drawings(if the shop drawings is not available, you can tell us the height from false ceiling to finished floor and width from wall to wall)
Secondly, we offer you the movable wall layout drawings for your confirmation
Thirdly, we quote the movable wall in accordance with confirmed drawings.

What is finishing face?


The bottom panel is MDF or plywood, which is unfinished face. You can do decoration on site, such as wallpaper, paint, etc.
We can also provide the product with finished face, such as faux wood, Woven fabric and Leather. Aluminum - Framed Acoustic Room Dividers Partitions For Multi - Purpose Hall
